Ford Escape: Exterior Lighting / Removal and Installation - Headlamp Assembly

Special Tool(s) / General Equipment

Ford Diagnostic Equipment

Removal

NOTE: Removal steps in this procedure may contain installation details.

NOTE: Vehicle equipped with halogen headlamps shown, light emitting diode (LED) headlamps similar.

  1. Remove the front bumper cover.
    Refer to: Front Bumper Cover (501-19 Bumpers, Removal and Installation).
  1. Remove the screws and position the headlamp assembly forward.
    Torque: 42 lb.in (4.8 Nm)
  1. Disconnect the headlamp electrical connector and remove the headlamp assembly.

Installation

  1. To install, reverse the removal procedure.
  1. NOTE: This step is only necessary when installing a new component.

    Adjust the headlamp assembly.
    Refer to: Headlamp Adjustment (417-01 Exterior Lighting, General Procedures).

Vehicles without HCM (headlamp control module).

  1. NOTE: This step is only necessary when installing a new component.

    Using a diagnostic scan tool, execute the "BCM > LIN New Module Initialization" routine. Follow the diagnostic scan tool directions.
    Use the General Equipment: Ford Diagnostic Equipment
