Ford Escape: Exterior Lighting / Removal and Installation - Headlamp Switch
Special Tool(s) /
General Equipment
Removal
NOTE:
Removal steps in this procedure may contain installation details.
-
Using a non-marring tool, release and position the headlamp switch out.
Use the General Equipment: Interior Trim Remover
-
Disconnect the electrical connector and remove the headlamp switch.
Installation
-
To install, reverse the removal procedure.
Removal
Low beam bulb, vehicles equipped with halogen headlamps
Remove the low beam headlamp bulb cover.
Remove the low beam headlamp bulb...
Special Tool(s) /
General Equipment
Interior Trim Remover
Removal
NOTE:
Removal steps in this procedure may contain installation details...
