Ford Escape: Engine / Removal and Installation - Oil Pressure Switch

Materials

Name Specification
Motorcraft® Thread Sealant with PTFE
TA-24-B
WSK-M2G350-A2


Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. With the vehicle in NEUTRAL, position it on a hoist.
    Refer to: Jacking and Lifting - Overview (100-02 Jacking and Lifting, Description and Operation).
  1. Remove the fasteners and undershield.
  1. Without oil cooler shown with oil cooler similar.
    Disconnect the electrical connector and remove the EOP switch.
    Material: Motorcraft® Thread Sealant with PTFE / TA-24-B (WSK-M2G350-A2)
    Torque: 97 lb.in (11 Nm)

Installation

  1. To install, reverse the removal procedure.
