Ford Escape: Climate Control System - General Information / Removal and Installation - Passenger Side Register

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Release the clips and remove the trim panel.

  1. Remove the bolts and the display unit.
    • Disconnect the electrical connector.
      Torque: 22 lb.in (2.5 Nm)

  1. Remove the bolts, release the clips and remove the center instrument panel trim panel.
    • Disconnect the electrical connector.
      Torque: 22 lb.in (2.5 Nm)
  1. Remove the bolt and the RH HVAC register.
    Torque: 22 lb.in (2.5 Nm)

Installation

  1. To install, reverse the removal procedure.
