Ford Escape: Climate Control System - General Information / Removal and Installation - In-Vehicle Temperature and Humidity Sensor

Removal

  1. Release the clips and remove the trim panel
    1. Disconnect the electrical connector.
    1. Release the tabs and remove the in-vehicle tempreature and humidty sensor.

Installation

  1. To install, reverse the removal procedure.
