Ford Escape 2020-2022 Service Manual / Powertrain / Automatic Transmission / Power Transfer Unit / Removal and Installation - Power Transfer Unit Input Shaft Seal RH

Ford Escape: Power Transfer Unit / Removal and Installation - Power Transfer Unit Input Shaft Seal RH

Special Tool(s) / General Equipment

100-001 (T50T-100-A)
Slide Hammer
205-153 (T80T-4000-W)
Handle
308-777
Remover and Installer, PTU Input Shaft Seal
308-970
Installer, RH halfshaft Seal
308-973
Remover, PTU Input Sleeve

Removal

  1. With the vehicle in NEUTRAL, position it on a hoist.
    Refer to: Jacking and Lifting - Overview (100-02 Jacking and Lifting, Description and Operation).
  1. Remove the intermediate shaft.
  1. Position the tool on top of the seal.
    Use Special Service Tool: 308-973  Remover, PTU Input Sleeve.
  1. NOTE: Make sure piercing tool stops on the sleeve tool for proper piercing of the seal.

    Using the tool, pierce the seal.
    Use Special Service Tool: 308-973  Remover, PTU Input Sleeve. , 308-777  Remover and Installer, PTU Input Shaft Seal.
  1. Install the screws and tighten until the tool firmly attaches to the seal.
    Use Special Service Tool: 308-973  Remover, PTU Input Sleeve.
  1. NOTE: Make sure piercing tool stops on the sleeve tool for proper piercing of the seal.

    Using the tool, pierce the seal.
    Use Special Service Tool: 308-973  Remover, PTU Input Sleeve. , 308-777  Remover and Installer, PTU Input Shaft Seal.
  1. Install the screws and tighten until the tool firmly attaches to the seal.
    Use Special Service Tool: 308-973  Remover, PTU Input Sleeve.
  1. Using the tool, remove the seal.
    Use Special Service Tool: 100-001 (T50T-100-A)  Slide Hammer.

Installation

  1. NOTE: Make sure that the new seal in installed correctly.


    Use Special Service Tool: 205-153 (T80T-4000-W)  Handle. , 308-970  Installer, RH halfshaft Seal.
  1. Install the intermediate shaft.
