Ford Escape: Power Transfer Unit / Removal and Installation - Power Transfer Unit Rear Seal
Special Tool(s) /
General Equipment
 |
205-199
(T83T-3132-A1)
Installer, Spindle/Axle Shaft T83-4000-A TKIT-1983-F TKIT-1983-FLM TKIT-1983-FX |
 |
308-777 Remover and Installer, PTU Input Shaft Seal |
.jpg) |
308-969 Installer, Pinion Seal |
Slide Hammer Dent Puller |
Plastic Mallet |
Two Leg Puller |
Removal
-
Remove the PTU.
-
Using the two leg puller remove the companion flange.
Use the General Equipment: Two Leg Puller
-
Remove and discard retaining clip.
-
Using the tool, pierce the seal. Remove and discard pinion seal using dent puller.
Use Special Service Tool: 308-777
Remover and Installer, PTU Input Shaft Seal.
Use the General Equipment: Slide Hammer Dent Puller
Installation
-
Position the tool on the pinion shaft.
Use Special Service Tool: 308-969
Installer, Pinion Seal.
-
Using the tool install the pinion seal.
Use Special Service Tool: 308-969
Installer, Pinion Seal.
, 205-199
(T83T-3132-A1)
Installer, Spindle/Axle Shaft.
-
Install new retaining clip.
-
NOTE:
Place wooden block on the flange and hammer on the wood using mallet.
Install the companion flange.
Use the General Equipment: Plastic Mallet
-
Install the PTU.
