Ford Escape: Information and Entertainment System - General Information / Removal and Installation - Rear Door Tweeter Speaker
Removal
NOTE:
LH rear door tweeter speaker is shown, RH rera door tweeter speaker is similar.
-
Remove the LH rear door interior trim panel.
Refer to: Rear Door Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).
-
Release the tabs and remove the tweeter speaker.
Installation
-
To install, reverse the removal procedure.
