Ford Escape: Information and Entertainment System - General Information / Removal and Installation - Satellite Radio / Global Positioning System (GPS) Antenna

Removal

  1. Lower the headliner.
    Refer to: Headliner - Lowering (501-05 Interior Trim and Ornamentation, Removal and Installation).
  1. Disconnect the electrical connector.

  1. Remove the satellite radio/GPS antenna.
    • Remove the bolt.
      Torque: 93 lb.in (10.5 Nm)
    • Remove the retainer.

Installation

Existing antenna

  1. To install, reverse the removal procedure.

New antenna

NOTE: If installing a new satellite radio/GPS antenna it is not necessary to remove the bolt from the satellite radio/ GPS antenna base.

  1. Install harness through the opening and push down until the base is fully seated.
  1. Connect the electrical connector.
  1. Install the headliner.
    Refer to: Headliner - Lowering (501-05 Interior Trim and Ornamentation, Removal and Installation).
