Ford Escape: Engine Cooling / Removal and Installation - Thermostat Housing

Special Tool(s) / General Equipment

Hose Clamp Remover/Installer

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Drain the cooling system.
    Refer to: Engine Cooling System Draining, Vacuum Filling and Bleeding (303-03C Engine Cooling, General Procedures).
  1. Detach the electrical wiring harness retainer.
  1. Release the clamps and disconnect the coolant hoses.
    Use the General Equipment: Hose Clamp Remover/Installer
  1. Remove the studbolt and the thermostat housing.
    Torque: 35 lb.ft (47.5 Nm)

Installation

  1. To install, reverse the removal procedure.
  1. Fill and bleed the cooling system.
    Refer to: Engine Cooling System Draining, Vacuum Filling and Bleeding (303-03C Engine Cooling, General Procedures).
