Ford Escape: Engine Cooling / Removal and Installation - Thermostat

Special Tool(s) / General Equipment

Hose Clamp Remover/Installer

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Drain the cooling system.
    Refer to: Engine Cooling System Draining, Vacuum Filling and Bleeding (303-03C Engine Cooling, General Procedures).
  1. Release the clamp and disconnect the coolant hose.
    Use the General Equipment: Hose Clamp Remover/Installer
  1. NOTE: During installation, make sure the coolant inlet connection is fully seated on the thermostat housing before tightening the bolts.

    Remove the bolts and detach the coolant inlet connector.
    Torque: 89 lb.in (10 Nm)
  1. Remove the thermostat. Remove and discard the O-ring seal.

Installation

  1. NOTE: Component(s) must be lubricated with clean engine coolant.

    Lubricate the new O-ring seal.
    Refer to: Specifications (303-03C Engine Cooling, Specifications).
  1. To install, reverse the removal procedure.
  1. Fill and bleed the cooling system.
    Refer to: Engine Cooling System Draining, Vacuum Filling and Bleeding (303-03C Engine Cooling, General Procedures).
