Ford Escape 2020-2024 Service Manual / Body and Paint / Body and Paint / Body Closures / Description and Operation - Body Closures - Component Location
Ford Escape: Body Closures / Description and Operation - Body Closures - Component Location
.jpg)
| Item | Description |
|---|---|
| 1 | Power liftgate motor |
| 2 | RGTM |
| 3 | Power liftgate latch |
| 4 | Hands-free liftgate actuation upper sensor (if equipped) |
| 5 | Hands-free liftgate actuation lower sensor (if equipped) |
| 6 | Hands-free liftgate actuation module (if equipped) |
| 7 | Liftgate anti-pinch switches |
Description and Operation - Body Closures - Overview
Overview
The power liftgate feature allows power opening and closing of the liftgate using any of the following methods:
The front power liftgate switch (located on the instrument panel)...
