Ford Escape 2020-2024 Service Manual / Electrical / Electrical Distribution / Module Communications Network / Description and Operation - Communications Network - System Operation and Component Description

Ford Escape: Module Communications Network / Description and Operation - Communications Network - System Operation and Component Description

System Operation

System Diagram

NOTE: For vehicles equipped with pre-collision assist, the CCM does not communicate directly on the HS-CAN2 . The CCM communicates with the IPMA on a private CAN , and the IPMA communicates on the HS-CAN2 . For description and diagnostic information, refer to Section 419-03B.


Item Description
1 DDM
2 PDM
3 DSP
4 ACM
5 SODL
6 SODR
7 RTM
8 PSCM
9 IPMA
10 RCM
11 ABS module
12 BCM
13 IPC
14 PCM
15 SCCM
16 HVAC module
17 ACCM
18 GSM
19 AWD module
20 OCS module
21 RGTM
22 TRM
23 PACM
24 BECMB
25 PAM
26 TCU
27 BCMC ( BJB )
28 DCDC
29 SOBDMC
30 APIM
31 DSM
32 GWM
33 DLC
34 DIAG 2 Transceiver
35 DIAG 1 Transceiver
36 HUD module
37 BECM
38 WACM
39 SOBDM (Battery Charging Control Module [BCCM])
40 PHEV
41 HEV / PHEV

  Module Network Chart


Module Name Network Type Terminating Module
ABS module   HS-CAN2 No
  ACM   HS-CAN3 No
ACCM ( HEV / PHEV )   HS-CAN1 No
APIM (if equipped)   HS-CAN1 No
  HS-CAN3 No
  HS-CAN4 No
AWD module (if equipped)   HS-CAN1 No
  BCM   HS-CAN1 No
BCMC [ BJB ] (if equipped)   HS-CAN1 No
BECM ( HEV / PHEV )   HS-CAN1 No
  BECMB   HS-CAN1 No
DCDC ( HEV / PHEV )   HS-CAN1 No
DDM (if equipped)   MS-CAN No
DSM (if equipped)   MS-CAN No
DSP (if equipped)   HS-CAN3 No
GSM (if equipped)   HS-CAN2 No
  GWM   HS-CAN1 Yes
  HS-CAN2 Yes
  HS-CAN3 Yes
  HS-CAN4 Yes
  MS-CAN Yes
HUD module (if equipped)   HS-CAN3 No
HVAC module   MS-CAN Yes
  IPC   HS-CAN3 Yes
IPMA (if equipped)   HS-CAN2 No
OCS module   HS-CAN2 No
PACM ( HEV / PHEV )   HS-CAN1 No
PAM (if equipped)   HS-CAN2 No
  PCM   HS-CAN1 Yes
PDM (if equipped)   MS-CAN No
  PSCM   HS-CAN2 No
  RCM   HS-CAN2 No
RGTM (if equipped)   MS-CAN No
RTM (if equipped)   MS-CAN No
  SCCM   HS-CAN2 Yes
SOBDM (Battery Charging Control Module [BCCM]) ( PHEV )   HS-CAN1 No
SOBDMC ( HEV / PHEV )   HS-CAN1 No
SODL (if equipped)   MS-CAN No
SODR (if equipped)   MS-CAN No
TCU (if equipped)   HS-CAN4 Yes
TRM (if equipped)   MS-CAN No
WACM (if equipped)   HS-CAN3 No

Network Termination

The CAN uses network termination to improve communication reliability. Termination modules are located at both ends of the network. As network messages are broadcast in the form of voltage signals, the network voltage signals are stabilized by the termination resistors.

Each termination module has an internal 120 ohm resistor that bridges across the positive and negative bus connection.

Network termination improves bus message reliability by stabilizing bus voltage and eliminating electrical interference.

Gateway Module

NOTE: The GWM communicates with the 4 or 5 (optional) controller area networks (CANs). The OBD DLC is fitted to the GWM and is the interface with the diagnostic scan tool.

The GWM is mounted under the driver side instrument panel. The OBD connector is fitted to the GWM . The GWM acts as a central gateway to translate messages across all vehicle controller area networks (CANs), and vice versa. The GWM is the only module on the vehicle with this ability. The GWM also serves as a termination module for each of the networks to which it is connected.

The 2 module communication networks connected to the DLC are DIAG 1 and DIAG 2. These 2 networks communicate directly with the diagnostic scan tool. The other communication networks, communicate on the network, but do not communicate directly with the diagnostic scan tool. The GWM translates the messages from the HS-CAN1 to DIAG 1. The GWM translates messages from the HS-CAN2 , HS-CAN3 , HS-CAN4 (if equipped) and MS-CAN to DIAG 2 which transfers the signals to the diagnostic scan tool.


Item Description
1 DIAG 1
2 DIAG 2
3 GWM
4 Transceiver
5 DLC
6 DIAG 2 Transceiver
7 DIAG 1 Transceiver
8 Transceiver
9 Transceiver
10 Transceiver
11 Transceiver

High Speed Controller Area Network 1 and 2 (HS-CAN1, HS-CAN2)

The HS-CAN1 and HS-CAN2 operate at a maximum data transfer speed of 500 Kbps and are designed for real time powertrain and driver feature information transfer and control. Modules on the HS-CAN1 and HS-CAN2 communicate using bussed messages. The HS-CAN uses an unshielded twisted pair cable, data bus (+) and data bus (-) circuits. In addition to diagnostic scan tool communication, the HS-CAN allows sharing of information between all modules on each HS-CAN .

With the addition of more modules, network traffic has increased. This has created the need for an additional HS-CAN to manage the increased bus data carried on each network.

The GWM translates the diagnostic messages from the DIAG 1 network to the HS-CAN1 and vice versa, allowing communication between the modules on the HS-CAN1 and diagnostic scan tool. The GWM translates the diagnostic messages from the DIAG 2 network to the HS-CAN2 and vice versa, allowing communication between the modules on the HS-CAN2 and diagnostic scan tool.

High Speed Controller Area Network 3 and 4 (HS-CAN3, HS-CAN4)

The HS-CAN3 and HS-CAN4 (if equipped) operate at a maximum data transfer speed of 500 Kbps and are designed for real time audio, multimedia and driver information transfer and control. Modules on the HS-CAN3 and HS-CAN4 (if equipped) communicate using bussed messages. HS-CAN3 and HS-CAN4 (if equipped) use an unshielded twisted pair cable, data bus (+) and data bus (-) circuits, and allows sharing of information between all modules on the network.

The GWM is used as a gateway for the messages to transfer between the diagnostic scan tool and the modules on the HS-CAN3 and HS-CAN4 (if equipped).

The GWM translates the diagnostic messages from the DIAG 2 to the HS-CAN3 and HS-CAN4 (if equipped) and vice versa, allowing communication between the modules on the HS-CAN3 and HS-CAN4 (if equipped) and the diagnostic scan tool.

Medium Speed Controller Area Network (MS-CAN)

The MS-CAN operates at a maximum data transfer speed of 125 Kbps and is designed for general information transfer. Modules on the MS-CAN communicate using bussed messages. The MS-CAN uses an unshielded twisted pair cable, data bus (+) and data bus (-) circuits. In addition to diagnostic scan tool communication, the MS-CAN allows sharing of information between all modules on the network.

The GWM is used as a gateway for the messages to transfer between the diagnostic scan tool and the modules on the MS-CAN .

The GWM translates the diagnostic messages from the DIAG 2 to the MS-CAN and vice versa, allowing communication between the modules on the MS-CAN and the diagnostic scan tool.

Controller Area Network (CAN) Fault Tolerance

NOTE: IDS shown, FDRS similar.

NOTE: The oscilloscope traces shown are from the IDS oscilloscope taken using the IDS pre-configured CAN settings. The traces are for both data (+) and data (-) taken simultaneously (2-channel) at a sample rate of 1 mega-sample per second (1MS/s) or greater.

Fault Tolerance Normal Operation

The data (+) and data (-) circuits are each regulated to approximately 2.5 volts during neutral or rested network traffic. As messages are sent on the data (+) circuit, voltage is increased by approximately 1.0 volt. Inversely, the data (-) circuit is reduced by approximately 1.0 volt when a message is sent.

Successful communication of a message can usually be identified by the slight spike at the end of a message transmission. Any signals that are significantly different than the normal CAN waveform may cause network Diagnostic Trouble Codes (DTCs) (U-codes) to set or may cause a complete network outage.

CAN Circuits Shorted Together

In the event the data (+) and data (-) circuits become shorted together, the signal stays at base voltage (2.5V) continuously and all communication capabilities are lost.

CAN (+) Circuit Shorted to Ground

In the event the data (+) circuit becomes shorted to ground, both the data (+) and data (-) circuits are pulled low (0V) and all communication capabilities are lost.

CAN (-) Circuit Shorted to Ground

In the event the data (-) circuit becomes shorted to ground, the data (-) circuit is pulled low (0V) and the data (+) circuit reaches near-normal peak voltage (3.0V) during communication but falls to 0V instead of normal base voltage (2.5V). Communication may continue but at a degraded level.

CAN (+) Circuit Shorted to Battery Voltage

In the event the data (+) circuit becomes shorted to battery voltage, the data (+) circuit is pulled high (12V) and the data (-) circuit falls to abnormally high voltage (above 5V) during communication and reaches battery voltage (12V) for peak voltage. Communication may continue but at a degraded level.

CAN (-) Circuit Shorted to Battery Voltage

In the event the data (-) circuit becomes shorted to battery voltage, both the data (+) and data (-) circuits are pulled high (12V) and all communication capabilities are lost.

CAN Circuit Signal Corruption

Rhythmic oscillations, inductive spikes or random interference can corrupt the network communications. The corruption signal source may be outside electrical interference such as motors or solenoids or internal interference generated from a module on the network. In some cases, an open in either the data (+) or data (-) circuit to a network module may cause the module to emit interference on the one circuit which is still connected. The trace shown is an example of a sawtooth pattern transmitted from a module with one open network circuit.

Other corruptions may be present when a module is intermittently powered up and down. The module on power up may initiate communication out of sync with other modules on the network causing momentary communication outages.

Controller Area Network (CAN) Multiplex Messages

The network communication message chart provides a high level description of key network messages for all communication networks on the vehicle. This information can be used to determine which modules are involved in completing a function including display of messages, status updates and commands.

Comparative functional checks can be performed without using test equipment to determine if faults exist in GWM data translation transfer paths. Specifically, this is accomplished by verifying that another feature/function works correctly which uses the same message translation paths through the GWM as the feature/function in question. The information listed in the communication message chart below provides the key reference information to make this possible.

Example:

The ability of the power running boards to extend when the driver door is opened confirms the ability of the GWM to successfully translate messages from the HS-CAN1 to the MS-CAN . If this function is not operating correctly, perform a comparative check for another function that is completed using the same translation path but with different originating and receiving modules. Refer to the comparative example below:





Network Message Originating Module Network Type Receiving Module(s)
Driver door ajar status   BCM   HS-CAN1
  • PCM
  • PAM
  • GWM
Driver door ajar status   GWM   MS-CAN
  • PRB

In this example the path for relaying gear lever position information from the PCM to the DDM is being used for a comparative functional check. The diagnostic scan tool display of the gear lever position information in the DDM was used to verify the functionality of the HS-CAN1 to MS-CAN path.





Network Message Originating Module Network Type Receiving Module(s)
Gear lever position   PCM   HS-CAN1
  • BCM
  • PAM
  • GWM
Gear lever position   GWM   MS-CAN
  • DDM
  • PDM
  • DSM
  • FCIM
  • PRB
  • SCMG
  • SCMH
  • SODL
  • SODR

  Communication Message Chart


Network Message Originating Module Network Type Receiving Module(s)
A/C clutch status   PCM   HS-CAN1
  • GWM
A/C clutch status   GWM   MS-CAN
  • HVAC module
A/C clutch status   GWM   HS-CAN3
  • IPC
A/C clutch status   GWM   HS-CAN4
  • TCU
ABS active ABS module   HS-CAN2
  • RCM
  • IPMA
  • PAM
  • PSCM
  • GWM
ABS active   GWM   HS-CAN1
  • AWD module
  • PCM
  • SOBDMC
ABS active   GWM   HS-CAN3
  • ACM
  • APIM
ABS active   GWM   HS-CAN4
  • TCU
ABS fault ABS module   HS-CAN2
  • GWM
ABS fault   GWM   HS-CAN1
  • PCM
  • SOBDMC
ABS fault   GWM   HS-CAN3
  • IPC
ABS fault   GWM   HS-CAN4
  • TCU
ABS warning indicator request ABS module   HS-CAN2
  • PAM
  • RCM
  • GWM
ABS warning indicator request   GWM   HS-CAN4
  • TCU
ABS warning indicator request   GWM   HS-CAN3
  • IPC
Accelerator pedal position   PCM   HS-CAN1
  • AWD module
  • BCM
  • SOBDMC
  • GWM
Accelerator pedal position   GWM   MS-CAN
  • HVAC module
Accelerator pedal position   GWM   HS-CAN2
  • RCM
  • ABS module
  • IPMA
  • OCS module
  • PAM
Accelerator pedal position   GWM   HS-CAN3
  • ACM
  • APIM
Accelerator pedal position   GWM   HS-CAN4
  • TCU
Accessory delay   BCM   HS-CAN1
  • GWM
Accessory delay   GWM   HS-CAN3
  • ACM
  • APIM
  • HUD module
  • IPC
  • WACM
Accessory delay   GWM   MS-CAN
  • DDM
  • PDM
Accessory delay   GWM   HS-CAN4
  • TCU
ACM configuration   ACM   HS-CAN3
  • APIM
  • IPC
Active noise audio status   ACM   HS-CAN3
  • DSP
Active park assist chime request   PAM   HS-CAN2
  • GWM
Active park assist chime request   GWM   HS-CAN3
  • IPC
Active park assist chime request   GWM   HS-CAN4
  • TCU
Active park assist message display   PAM   HS-CAN2
  • GWM
Active park assist message display   GWM   HS-CAN3
  • ACM
  • APIM
Active park assist message display   GWM   HS-CAN4
  • TCU
Active park assist mode available   PAM   HS-CAN2
  • GWM
Active park assist mode available   GWM   HS-CAN4
  • TCU
Active park assist mode available   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
Active park assist mode request   APIM   HS-CAN3
  • GWM
Active park assist mode request   GWM   HS-CAN2
  • PAM
Active park assist status   PAM   HS-CAN2
  • GWM
Active park assist status   GWM   HS-CAN1
  • PCM
Active park assist status   GWM   HS-CAN4
  • TCU
Active park assist status   GWM   HS-CAN3
  • APIM
  • IPC
Active park assist steering angle control status   PSCM   HS-CAN2
  • PAM
  • GWM
Active park assist steering angle control status   GWM   HS-CAN4
  • TCU
Active park assist steering angle request   PAM   HS-CAN2
  • ABS module
  • PSCM
  • GWM
Active park assist steering angle request   GWM   HS-CAN1
  • BCM
Active park assist steering angle request   GWM   HS-CAN4
  • TCU
Adaptive cruise control cancel request   IPMA   HS-CAN2
  • GWM
Adaptive cruise control cancel request   GWM   HS-CAN1
  • PCM
Adaptive cruise control cancel request   GWM   HS-CAN4
  • TCU
Adaptive cruise control commands   SCCM   HS-CAN2
  • IPMA
  • GWM
Adaptive cruise control commands   GWM   HS-CAN1
  • PCM
Adaptive cruise control commands   GWM   HS-CAN4
  • TCU
Adaptive cruise control deceleration request   IPMA   HS-CAN2
  • ABS
  • RCM
  • GWM
Adaptive cruise control deceleration request   GWM   HS-CAN4
  • TCU
Adaptive cruise control enable request   IPC   HS-CAN3
  • HUD module
  • GWM
Adaptive cruise control enable request   GWM   HS-CAN2
  • IPMA
Adaptive cruise control enable request   GWM   HS-CAN4
  • TCU
Adaptive cruise control engine status   PCM   HS-CAN1
  • GWM
Adaptive cruise control engine status   GWM   HS-CAN2
  • IPMA
Adaptive cruise control engine status   GWM   HS-CAN4
  • TCU
Adaptive cruise control follow mode display   IPMA   HS-CAN2
  • GWM
Adaptive cruise control follow mode display   GWM   HS-CAN3
  • HUD module
  • IPC
Adaptive cruise control follow mode display   GWM   HS-CAN4
  • TCU
Adaptive cruise control forward distance alert   IPMA   HS-CAN2
  • GWM
Adaptive cruise control forward distance alert   GWM   HS-CAN3
  • IPC
Adaptive cruise control forward distance alert   GWM   HS-CAN4
  • TCU
Adaptive cruise control gap distance display   IPMA   HS-CAN2
  • GWM
Adaptive cruise control gap distance display   GWM   HS-CAN3
  • HUD module
  • IPC
Adaptive cruise control gap distance display   GWM   HS-CAN4
  • TCU
Adaptive cruise control gap select   SCCM   HS-CAN2
  • IPMA
  • GWM
Adaptive cruise control gap select   GWM   HS-CAN1
  • PCM
Adaptive cruise control gap select   GWM   HS-CAN4
  • TCU
Adaptive cruise control message display   IPMA   HS-CAN2
  • GWM
Adaptive cruise control message display   GWM   HS-CAN3
  • HUD module
  • IPC
Adaptive cruise control message display   GWM   HS-CAN4
  • TCU
Adaptive cruise control stop/resume display   IPMA   HS-CAN2
  • GWM
Adaptive cruise control stop/resume display   GWM   HS-CAN3
  • HUD module
  • IPC
Adaptive cruise control stop/resume display   GWM   HS-CAN4
  • TCU
Adaptive cruise control resume enable request   IPMA   HS-CAN2
  • GWM
Adaptive cruise control resume enable request   GWM   HS-CAN1
  • PCM
Adaptive cruise control resume enable request   GWM   HS-CAN4
  • TCU
Adaptive cruise control service required   IPMA   HS-CAN2
  • GWM
Adaptive cruise control service required   GWM   HS-CAN3
  • IPC
Adaptive cruise control service required   GWM   HS-CAN4
  • TCU
Adaptive cruise control stop active ABS module   HS-CAN2
  • IPMA
  • GWM
Adaptive cruise control stop active   GWM   HS-CAN1
  • PCM
Adaptive cruise control stop active   GWM   HS-CAN4
  • TCU
Adaptive cruise control stop mode   IPMA   HS-CAN2
  • GWM
Adaptive cruise control stop mode   GWM   HS-CAN3
  • HUD module
  • IPC
Adaptive cruise control stop mode   GWM   HS-CAN4
  • TCU
Adaptive cruise control stop mode request   PCM   HS-CAN1
  • GWM
Adaptive cruise control stop mode request   GWM   HS-CAN2
  • ABS module
  • IPMA
Adaptive cruise control stop mode request   GWM   HS-CAN4
  • TCU
Adaptive cruise control stop status request   IPMA   HS-CAN2
  • ABS module
  • GWM
Adaptive cruise control stop status request   GWM   HS-CAN1
  • PCM
Adaptive cruise control stop status request   GWM   HS-CAN4
  • TCU
Adaptive cruise control target distance display   IPMA   HS-CAN2
  • GWM
Adaptive cruise control target distance display   GWM   HS-CAN3
  • HUD module
  • IPC
Adaptive cruise control target distance display   GWM   HS-CAN4
  • TCU
Adaptive cruise control warning request   IPMA   HS-CAN2
  • GWM
Adaptive cruise control warning request   GWM   HS-CAN3
  • HUD module
  • IPC
Adaptive cruise control warning request   GWM   HS-CAN4
  • TCU
Airbag deployment status   RCM   HS-CAN2
  • GWM
Airbag deployment status   GWM   HS-CAN1
  • APIM
Airbag deployment status   GWM   HS-CAN3
  • ACM
Airbag warning indicator request   RCM   HS-CAN2
  • GWM
Airbag warning indicator request   GWM   HS-CAN3
  • IPC
Airbag warning indicator request   GWM   HS-CAN4
  • TCU
Ambient air temperature   PCM   HS-CAN1
  • AWD module
  • BCM
  • DCDC
  • SOBDM (Battery Charging Control Module [BCCM])
  • GWM
Ambient air temperature   GWM   MS-CAN
  • HVAC module
Ambient air temperature   GWM   HS-CAN3
  • IPC
Ambient air temperature   GWM   HS-CAN2
  • ABS module
  • PAM
  • SCCM
Ambient air temperature   GWM   HS-CAN4
  • TCU
Ambient air temperature filtered   PCM   HS-CAN1
  • ACCM
  • BCM
  • SOBDMC
  • GWM
Ambient air temperature filtered   GWM   HS-CAN2
  • IPMA
Ambient air temperature filtered   GWM   MS-CAN
  • HVAC module
Ambient air temperature filtered   GWM   HS-CAN3
  • IPC
Ambient air temperature filtered   GWM   HS-CAN4
  • TCU
Ambient lighting color/intensity   BCM   HS-CAN1
  • GWM
Ambient lighting color/intensity   GWM   HS-CAN3
  • APIM
Ambient lighting color/intensity   GWM   HS-CAN4
  • TCU
Ambient lighting color/intensity request   APIM   HS-CAN3
  • GWM
Ambient lighting color/intensity request   GWM   HS-CAN1
  • BCM
Ambient light sensor   SCCM   HS-CAN2
  • IPMA
  • GWM
Ambient light sensor   GWM   HS-CAN1
  • BCM
Audio chime status   ACM   HS-CAN3
  • DSP
  • IPC
Audio system response status   ACM   HS-CAN3
  • APIM
  • DSP
  • HUD module
  • IPC
Audio system source status   ACM   HS-CAN3
  • APIM
  • DSP
  • HUD module
  • IPC
  • WACM
  • GWM
Audio system source status   GWM   HS-CAN4
  • TCU
Audio volume   ACM   HS-CAN3
  • APIM
  • HUD module
  • IPC
Audio-navigation switch button status   SCCM   HS-CAN2
  • GWM
Audio-navigation switch button status   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
Auto high beam headlamp request   SCCM   HS-CAN2
  • GWM
Auto high beam headlamp request   GWM   HS-CAN1
  • BCM
Auto high beam indication request   IPMA   HS-CAN2
  • SCCM
  • GWM
Auto high beam indication request   GWM   HS-CAN3
  • IPC
Auto high beam indication request   GWM   HS-CAN4
  • TCU
Auto hold message request ABS module   HS-CAN2
  • GWM
Auto hold message request   GWM   HS-CAN3
  • IPC
Auto hold switch mode indicator ABS module   HS-CAN2
  • GWM
Auto hold switch mode indicator   GWM   MS-CAN
  • HVAC module
Auto hold switch mode indicator   GWM   HS-CAN3
  • APIM
Auto tow active status   PCM   HS-CAN1
  • GWM
Auto tow active status   GWM   HS-CAN2
  • ABS module
  • IPMA
Auto tow active status   GWM   HS-CAN3
  • IPC
Auto tow active status   GWM   HS-CAN4
  • TCU
Auto tow allow request menu   IPC   HS-CAN3
  • GWM
Auto tow allow request menu   GWM   HS-CAN1
  • PCM
Auto tow allow status menu   PCM   HS-CAN1
  • GWM
Auto tow allow status menu   GWM   HS-CAN3
  • IPC
Auto tow allow status menu   GWM   HS-CAN4
  • TCU
Backlit LED status   BCM   HS-CAN1
  • GWM
Backlit LED status   GWM   HS-CAN3
  • APIM
  • WACM
Backlit LED status   GWM   MS-CAN
  • DDM
  • HVAC module
  • PDM
Backlit LED status   GWM   HS-CAN2
  • GSM
Backlit LED status   GWM   HS-CAN4
  • TCU
Battery low state of charge   BCM   HS-CAN1
  • GWM
Battery low state of charge   GWM   MS-CAN
  • HVAC module
  • TRM
Battery low state of charge   GWM   HS-CAN3
  • IPC
  • APIM
Battery low state of charge   GWM   HS-CAN4
  • TCU
Battery saver status   BCM   HS-CAN1
  • BCMC [ BJB ]
  • GWM
Battery saver status   GWM   HS-CAN3
  • ACM
  • DSP
Battery saver status   GWM   HS-CAN4
  • TCU
Battery saver status   GWM   MS-CAN
  • DDM
  • PDM
BLIS LED status driver side   DDM   MS-CAN
  • SODL
  • SODR
BLIS LED status passenger side   PDM   MS-CAN
  • SODL
  • SODR
BLIS trailer tow left data   SODL   MS-CAN
  • SODR
BLIS trailer tow left status   SODL   MS-CAN
  • SODR
  • GWM
BLIS trailer tow left status   GWM   HS-CAN3
  • IPC
BLIS trailer tow right data   SODR   MS-CAN
  • SODL
BLIS trailer tow right status   SODR   MS-CAN
  • SODL
  • GWM
BLIS trailer tow right status   GWM   HS-CAN3
  • IPC
Body service required   BCM   HS-CAN1
  • GWM
Body service required   GWM   HS-CAN3
  • IPC
Body service required   GWM   HS-CAN4
  • TCU
Brake (red) warning indicator request ABS module   HS-CAN2
  • RCM
  • GWM
Brake (red) warning indicator request   GWM   HS-CAN3
  • IPC
Brake (red) warning indicator request   GWM   HS-CAN4
  • TCU
Brake auto hold status ABS module   HS-CAN2
  • IPMA
  • PAM
  • GWM
Brake auto hold status   GWM   HS-CAN1
  • PCM
Brake chime request ABS module   HS-CAN2
  • GWM
Brake chime request   GWM   HS-CAN3
  • IPC
Brake chime request   GWM   HS-CAN4
  • TCU
Brake lamp request ABS module   HS-CAN2
  • RCM
  • GWM
Brake lamp request   GWM   HS-CAN3
  • IPC
Brake lamp request   GWM   HS-CAN4
  • TCU
Brake pedal applied   PCM   HS-CAN1
  • AWD module
  • SOBDMC
  • GWM
Brake pedal applied   GWM   HS-CAN2
  • ABS module
  • GSM
  • IPMA
  • OCS module
  • PAM
  • RCM
Brake pedal applied   GWM   HS-CAN3
  • APIM
  • IPC
Brake pedal applied   GWM   HS-CAN4
  • TCU
Brake pedal movement ABS module   HS-CAN2
  • GWM
Brake pedal movement   GWM   HS-CAN1
  • PCM
Brake pedal movement   GWM   HS-CAN4
  • TCU
Brake shift interlock status   BCM   HS-CAN1
  • PCM
  • GWM
Brake shift interlock status   GWM   HS-CAN2
  • GSM
Brake switch position (gear shift by wire)   GSM   HS-CAN2
  • GWM
Brake switch position (gear shift by wire)   GWM   HS-CAN1
  • PCM
Brake switch position (gear shift by wire)   GWM   HS-CAN4
  • TCU
Brake warning indicator request   BCM   HS-CAN1
  • GWM
Brake warning indicator request   GWM   HS-CAN3
  • IPC
Brake warning indicator request   GWM   HS-CAN4
  • TCU
Camera settings   BCM   HS-CAN1
  • GWM
Camera settings   GWM   HS-CAN3
  • APIM
Camera settings   GWM   HS-CAN4
  • TCU
Camera settings request   APIM   HS-CAN3
  • IPC
  • GWM
Camera settings request   GWM   HS-CAN1
  • BCM
Camera status display   IPMA   HS-CAN2
  • GWM
Camera status display   GWM   HS-CAN3
  • IPC
Camera status display   GWM   HS-CAN4
  • TCU
CD load/eject   ACM   HS-CAN3
  • APIM
Cell phone chirp request   TCU   HS-CAN4
  • GWM
Cell phone chirp request   GWM   HS-CAN1
  • BCM
Cell phone lock request   TCU   HS-CAN4
  • GWM
Cell phone lock request   GWM   HS-CAN1
  • BCM
Center stack display configuration   APIM   HS-CAN1
  • BCM
  • PCM
  • GWM
Center stack display configuration   GWM   HS-CAN2
  • IPMA
  • SCCM
Center stack display configuration   GWM   HS-CAN3
  • IPC
Center stack display configuration   GWM   HS-CAN4
  • TCU
Center stack display configuration   GWM   MS-CAN
  • DDM
  • DSM
  • HVAC module
  • PDM
Check fuel fill inlet message display   PCM   HS-CAN1
  • GWM
Check fuel fill inlet message display   GWM   HS-CAN3
  • IPC
Check fuel fill inlet message display   GWM   HS-CAN4
  • TCU
Child lock request   BCM   HS-CAN1
  • GWM
Child lock request   GWM   HS-CAN4
  • TCU
Child lock request   GWM   MS-CAN
  • DDM
Chime active   ACM   HS-CAN3
  • DSP
  • GWM
Chime active   GWM   HS-CAN4
  • TCU
Chime controls   IPC   HS-CAN3
  • ACM
  • DSP
Chime power up   IPC   HS-CAN3
  • ACM
  • DSP
Chime source   IPC   HS-CAN3
  • ACM
  • DSP
Climate control button status HVAC module   MS-CAN
  • RGTM
  • GWM
Climate control button status   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
Climate control temperature display HVAC module   MS-CAN
  • GWM
Climate control temperature display   GWM   HS-CAN3
  • APIM
  • IPC
Collision avoidance and driver support chime request   IPMA   HS-CAN2
  • GWM
Collision avoidance and driver support chime request   GWM   HS-CAN3
  • IPC
Collision avoidance and driver support chime request   GWM   HS-CAN4
  • TCU
Collision avoidance and driver support radar blocked warning   IPMA   HS-CAN2
  • GWM
Collision avoidance and driver support radar blocked warning   GWM   HS-CAN3
  • HUD module
  • IPC
Collision avoidance and driver support radar blocked warning   GWM   HS-CAN4
  • TCU
Collision mitigation brake precharge request   IPMA   HS-CAN2
  • ABS module
  • RCM
  • GWM
Collision mitigation brake precharge request   GWM   HS-CAN4
  • TCU
Collision mitigation by braking brake precharge status ABS module   HS-CAN2
  • IPMA
  • GWM
Collision mitigation by braking brake precharge status   GWM   HS-CAN1
  • PCM
Collision mitigation by braking brake precharge status   GWM   HS-CAN4
  • TCU
Collision mitigation by braking deceleration status ABS module   HS-CAN2
  • IPMA
  • GWM
Collision mitigation by braking deceleration status   GWM   HS-CAN1
  • PCM
Collision mitigation by braking enable request   IPMA   HS-CAN2
  • RCM
  • GWM
Collision mitigation by braking enable request   GWM   HS-CAN1
  • PCM
Collision mitigation by braking enable request   GWM   HS-CAN4
  • TCU
Crash event status   BCM   HS-CAN1
  • BCMC [ BJB ]
  • GWM
Crash event status   GWM   MS-CAN
  • HVAC module
Crash event status   GWM   HS-CAN4
  • TCU
Cross traffic alert chime   IPC   HS-CAN3
  • GWM
Cross traffic alert chime   GWM   MS-CAN
  • SODL
  • SODR
Cross traffic alert chime   GWM   HS-CAN4
  • TCU
Cross traffic alert left status   SODL   MS-CAN
  • DDM
  • PDM
  • GWM
Cross traffic alert left status   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
Cross traffic alert right status   SODR   MS-CAN
  • DDM
  • PDM
  • GWM
Cross traffic alert right status   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
Cross traffic left sensor status   SODL   MS-CAN
  • SODR
  • GWM
Cross traffic left sensor status   GWM   HS-CAN3
  • IPC
Cross traffic right sensor status   SODR   MS-CAN
  • SODL
  • GWM
Cross traffic right sensor status   GWM   HS-CAN3
  • IPC
Cruise control mode   PCM   HS-CAN1
  • GWM
Cruise control mode   GWM   HS-CAN2
  • ABS module
Cruise control mode   GWM   HS-CAN4
  • TCU
Cruise control override   PCM   HS-CAN1
  • GWM
Cruise control override   GWM   HS-CAN3
  • HUD module
  • IPC
Cruise control override   GWM   HS-CAN2
  • ABS module
  • IPMA
  • RCM
Cruise control override   GWM   HS-CAN4
  • TCU
Cruise control set speed display   PCM   HS-CAN1
  • GWM
Cruise control set speed display   GWM   HS-CAN2
  • IPMA
Cruise control set speed display   GWM   HS-CAN3
  • HUD module
  • IPC
Cruise control set speed display   GWM   HS-CAN4
  • TCU
Cruise control set speed request   PCM   HS-CAN1
  • GWM
Cruise control set speed request   GWM   HS-CAN2
  • IPMA
Cruise control set speed request   GWM   HS-CAN3
  • IPC
Cruise control set speed request   GWM   HS-CAN4
  • TCU
Cruise control status   PCM   HS-CAN1
  • SOBDMC
  • GWM
Cruise control status   GWM   HS-CAN3
  • HUD module
  • IPC
Cruise control status   GWM   HS-CAN2
  • ABS module
  • IPMA
  • OCS module
  • RCM
  • SCCM
Cruise control status   GWM   HS-CAN4
  • TCU
Cruise control status   GWM   MS-CAN
  • HVAC module
CTA target left   SODL   MS-CAN
  • SODR
CTA target right   SODR   MS-CAN
  • SODL
Date/time display   APIM   HS-CAN3
  • DSP
  • IPC
Date/time settings   APIM   HS-CAN3
  • IPC
Day/night status   BCM   HS-CAN1
  • PCM
  • SOBDM (Battery Charging Control Module [BCCM])
  • GWM
Day/night status   GWM   MS-CAN
  • DDM
  • HVAC module
  • PDM
Day/night status   GWM   HS-CAN3
  • ACM
  • APIM
  • HUD module
  • IPC
  • WACM
Day/night status   GWM   HS-CAN2
  • GSM
  • IPMA
  • PAM
  • RCM
Day/night status   GWM   HS-CAN4
  • TCU
Daytime running lamps on status   BCM   HS-CAN1
  • GWM
Daytime running lamps on status   GWM   HS-CAN3
  • IPC
Daytime running lamps on status   GWM   HS-CAN4
  • TCU
Display language request   APIM   HS-CAN3
  • IPC
Display speed offset data   IPC   HS-CAN3
  • GWM
Display speed offset data   GWM   HS-CAN1
  • PCM
Display speed offset data   GWM   HS-CAN2
  • IPMA
Do not disturb override status   IPC   HS-CAN3
  • APIM
Door latch message request   BCM   HS-CAN1
  • GWM
Door latch message request   GWM   HS-CAN3
  • IPC
Door latch message request   GWM   HS-CAN4
  • TCU
Drive mode indication   IPC   HS-CAN3
  • HUD module
Drive mode select message reset   IPC   HS-CAN3
  • GWM
Drive mode select message reset   GWM   HS-CAN2
  • ABS module
Drive mode select mode message request ABS module   HS-CAN2
  • GWM
Drive mode select mode message request   GWM   HS-CAN3
  • IPC
Drive mode select position status ABS module   HS-CAN2
  • GWM
Drive mode select position status   GWM   HS-CAN3
  • IPC
Drive mode select request ABS module   HS-CAN2
  • PSCM
Drive mode select status   PSCM   HS-CAN2
  • ABS module
  • GWM
Drive mode select status   PCM   HS-CAN1
  • GWM
Drive mode select status   GWM   HS-CAN3
  • IPC
Drive mode select status   GWM   HS-CAN2
  • ABS module
Drive mode select status   GWM   HS-CAN4
  • TCU
Drive mode switch status   SCCM   HS-CAN2
  • GWM
Drive mode switch status   GWM   HS-CAN3
  • IPC
Driver door ajar status   BCM   HS-CAN1
  • PCM
  • GWM
Driver door ajar status   GWM   HS-CAN2
  • ABS module
  • GSM
  • IPMA
  • PAM
Driver door ajar status   GWM   HS-CAN3
  • ACM
  • APIM
  • HUD module
  • IPC
  • WACM
Driver door ajar status   GWM   HS-CAN4
  • TCU
Driver door ajar status   GWM   MS-CAN
  • DDM
  • DSM
  • HVAC module
  • PDM
  • RGTM
  • SODL
  • SODR
Driver door lock switch status   DDM   MS-CAN
  • GWM
Driver door lock switch status   GWM   HS-CAN1
  • BCM
Driver seat belt buckle deploy status   RCM   HS-CAN2
  • GWM
Driver seat belt buckle deploy status   GWM   HS-CAN3
  • APIM
Driver seat belt buckle status   RCM   HS-CAN2
  • ABS module
  • GSM
  • IPMA
  • GWM
Driver seat belt buckle status   GWM   HS-CAN3
  • IPC
Driver seat belt buckle status   GWM   HS-CAN1
  • BCM
  • PCM
  • SOBDMC
Driver seat belt buckle status   GWM   HS-CAN4
  • TCU
Driver set temperature   APIM   HS-CAN3
  • GWM
Driver set temperature   GWM   MS-CAN
  • HVAC module
DSP volume status   DSP   HS-CAN3
  • APIM
  • HUD module
eCall confirmation   APIM   HS-CAN1
  • BCM
  • GWM
eCall confirmation   GWM   HS-CAN2
  • RCM
eCall notification   RCM   HS-CAN2
  • GWM
eCall notification   GWM   HS-CAN1
  • APIM
eCall notification   GWM   HS-CAN4
  • TCU
Electronic park brake (red) indicator request ABS module   HS-CAN2
  • GWM
Electronic park brake (red) indicator request   GWM   HS-CAN3
  • IPC
Electronic park brake (red) indicator request   GWM   HS-CAN4
  • TCU
Electronic park brake (yellow) indicator request ABS module   HS-CAN2
  • GWM
Electronic park brake (yellow) indicator request   GWM   HS-CAN3
  • IPC
Electronic park brake (yellow) indicator request   GWM   HS-CAN4
  • TCU
Emergency assist override status   IPC   HS-CAN3
  • APIM
Emergency brake lamp request ABS module   HS-CAN2
  • GWM
Emergency brake lamp request   GWM   HS-CAN1
  • BCM
Emergency brake lamp request   GWM   HS-CAN4
  • TCU
Emergency call mute status   TCU   HS-CAN4
  • GWM
Emergency call mute status   GWM   HS-CAN3
  • ACM
  • APIM
  • DSP
Engine coolant temperature data   PCM   HS-CAN1
  • AWD module
  • BCM
  • GWM
Engine coolant temperature data   GWM   HS-CAN2
  • GSM
Engine coolant temperature data   GWM   HS-CAN3
  • IPC
  • APIM
Engine coolant temperature data   GWM   HS-CAN4
  • TCU
Engine coolant temperature data   GWM   MS-CAN
  • HVAC module
Engine idle shutdown message request   PCM   HS-CAN1
  • GWM
Engine idle shutdown message request   GWM   HS-CAN3
  • IPC
Engine idle shutdown message request   GWM   HS-CAN4
  • TCU
Engine idle shutdown status   PCM   HS-CAN1
  • BCM
  • GWM
Engine idle shutdown status   GWM   HS-CAN3
  • IPC
Engine idle shutdown status   GWM   HS-CAN4
  • TCU
Engine off status   BCM   HS-CAN1
  • AWD module
  • PCM
  • GWM
Engine off status   GWM   HS-CAN2
  • ABS module
  • IPMA
Engine off status   GWM   HS-CAN3
  • IPC
Engine off status   GWM   HS-CAN4
  • TCU
Engine off status   GWM   MS-CAN
  • HVAC module
Engine oil life   PCM   HS-CAN1
  • GWM
Engine oil life   GWM   HS-CAN3
  • IPC
  • APIM
Engine oil life   GWM   HS-CAN4
  • TCU
Engine oil life data reset   IPC   HS-CAN3
  • GWM
Engine oil life data reset   GWM   HS-CAN1
  • PCM
Engine overheat indication request   PCM   HS-CAN1
  • GWM
Engine overheat indication request   GWM   HS-CAN3
  • IPC
Engine overheat indication request   GWM   HS-CAN4
  • TCU
Engine rpm data   PCM   HS-CAN1
  • AWD module
  • BCM
  • BECM
  • GWM
Engine rpm data   GWM   HS-CAN3
  • DSP
  • HUD module
  • IPC
Engine rpm data   GWM   HS-CAN2
  • ABS module
  • GSM
  • RCM
Engine rpm data   GWM   MS-CAN
  • HVAC module
Engine rpm data   GWM   HS-CAN4
  • TCU
Engine service required request   PCM   HS-CAN1
  • GWM
Engine service required request   GWM   HS-CAN2
  • RCM
Engine service required request   GWM   HS-CAN3
  • IPC
Engine service required request   GWM   HS-CAN4
  • TCU
Engine status   PCM   HS-CAN1
  • BCM
  • GWM
Engine status   GWM   HS-CAN2
  • ABS module
Engine status   GWM   MS-CAN
  • HVAC module
Engine status   GWM   HS-CAN3
  • ACM
  • APIM
  • DSP
  • IPC
Engine status   GWM   HS-CAN4
  • TCU
English/metric mode   IPC   HS-CAN3
  • HUD module
  • GWM
English/metric mode   GWM   HS-CAN1
  • PCM
English/metric mode   GWM   MS-CAN
  • HVAC module
English/metric mode   GWM   HS-CAN2
  • IPMA
EPAS failure   PSCM   HS-CAN2
  • PAM
  • GWM
EPAS failure   GWM   HS-CAN3
  • IPC
EPAS failure   GWM   HS-CAN4
  • TCU
ePRNDL mode   IPC   HS-CAN3
  • GWM
ePRNDL mode   GWM   HS-CAN1
  • BCM
ePRNDL mode   GWM   HS-CAN2
  • GSM
Factory mode   BCM   HS-CAN1
  • AWD module
  • BCMC [ BJB ]
  • PACM
  • PCM
  • SOBDM (Battery Charging Control Module [BCCM])
  • SOBDMC
  • GWM
Factory mode   GWM   HS-CAN2
  • ABS module
  • GSM
  • IPMA
  • PAM
  • PSCM
  • SCCM
Factory mode   GWM   MS-CAN
  • DDM
  • DSM
  • HVAC module
  • PDM
  • RGTM
  • RTM
  • TRM
Factory mode   GWM   HS-CAN3
  • ACM
  • APIM
  • DSP
  • HUD module
  • IPC
  • WACM
Factory mode   GWM   HS-CAN4
  • TCU
Folder/track information request   APIM   HS-CAN3
  • ACM
Forward collision chime request   IPMA   HS-CAN2
  • GWM
Forward collision chime request   GWM   HS-CAN3
  • IPC
Forward collision chime request   GWM   HS-CAN4
  • TCU
Forward collision warning message request   IPMA   HS-CAN2
  • GWM
Forward collision warning message request   GWM   HS-CAN3
  • HUD module
  • IPC
Forward collision warning message request   GWM   HS-CAN4
  • TCU
Front fog lamp indicator request   BCM   HS-CAN1
  • GWM
Front fog lamp indicator request   GWM   HS-CAN2
  • IPMA
Front fog lamp indicator request   GWM   HS-CAN3
  • IPC
  • WACM
Front fog lamp indicator request   GWM   HS-CAN4
  • TCU
Front passenger detect status   RCM   HS-CAN2
  • GWM
Front passenger detect status   GWM   HS-CAN3
  • IPC
Front passenger detect status   GWM   MS-CAN
  • HVAC module
Front passenger detect status   GWM   HS-CAN4
  • TCU
Front wiper status   SCCM   HS-CAN2
  • ABS module
  • IPMA
  • GWM
Front wiper status   GWM   HS-CAN1
  • AWD module
  • BCM
  • PCM
Front wiper status   GWM   MS-CAN
  • HVAC module
  • SODL
  • SODR
Front wiper status   GWM   HS-CAN3
  • APIM
  • HUD module
Front wiper status   GWM   HS-CAN4
  • TCU
Fuel consumption display   IPC   HS-CAN3
  • APIM
  • GWM
Fuel consumption display   GWM   HS-CAN4
  • TCU
Fuel flow volume display   PCM   HS-CAN1
  • GWM
Fuel flow volume display   GWM   HS-CAN3
  • IPC
Fuel flow volume display   GWM   HS-CAN4
  • TCU
Fuel level data   IPC   HS-CAN3
  • GWM
Fuel level data   GWM   HS-CAN1
  • PCM
Fuel level display   PCM   HS-CAN1
  • GWM
Fuel level display   GWM   HS-CAN3
  • ACM
  • APIM
  • IPC
Fuel level percent display   IPC   HS-CAN3
  • APIM
  • GWM
Fuel level percent display   GWM   HS-CAN4
  • TCU
Fuel level percent display (engine)   PCM   HS-CAN1
  • GWM
Fuel level percent display (engine)   GWM   HS-CAN4
  • TCU
Fuel level warning   IPC   HS-CAN3
  • ACM
  • HUD module
Fuel pump power status   BCM   HS-CAN1
  • PCM
  • GWM
Fuel pump power status   GWM   HS-CAN4
  • TCU
Fuel range display   IPC   HS-CAN3
  • ACM
  • APIM
  • HUD module
  • GWM
Fuel range display   GWM   HS-CAN4
  • TCU
Fuel range display engine   PCM   HS-CAN1
  • GWM
Fuel range display engine   GWM   HS-CAN4
  • TCU
Gear lever display   PCM   HS-CAN1
  • GWM
Gear lever display   GWM   HS-CAN2
  • ABS module
  • GSM
  • PAM
Gear lever display   GWM   HS-CAN4
  • TCU
Gear lever position   PCM   HS-CAN1
  • AWD module
  • BCM
  • BECM
  • DCDC
  • PACM
  • SOBDM (Battery Charging Control Module [BCCM])
  • GWM
Gear lever position   GWM   HS-CAN2
  • ABS module
  • GSM
  • IPMA
  • RCM
  • SCCM
Gear lever position   GWM   HS-CAN3
  • ACM
  • APIM
  • IPC
  • DSP
Gear lever position   GWM   MS-CAN
  • DDM
  • DSM
  • HVAC module
  • PDM
  • RGTM
  • SODL
  • SODR
Gear lever position   GWM   HS-CAN4
  • TCU
Gear position   PCM   HS-CAN1
  • GWM
Gear position   GWM   HS-CAN2
  • ABS module
  • GSM
  • PAM
Gear position   GWM   HS-CAN4
  • TCU
Gear select button stuck (shift by wire)   GSM   HS-CAN2
  • GWM
Gear select button stuck (shift by wire)   GWM   HS-CAN1
  • PCM
Gear select button stuck (shift by wire)   GWM   HS-CAN4
  • TCU
Gear select lock (shift by wire)   PCM   HS-CAN1
  • GWM
Gear select lock (shift by wire)   GWM   HS-CAN2
  • GSM
Gear select lock (shift by wire)   GWM   HS-CAN4
  • TCU
Global clock data   BCM   HS-CAN1
  • SOBDMC
  • GWM
Global clock data   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
Global clock data   GWM   HS-CAN4
  • TCU
Global clock data   GWM   MS-CAN
  • TRM
Global clock display   APIM   HS-CAN3
  • IPC
  • GWM
Global clock display   GWM   HS-CAN1
  • BCM
Global clock message display   IPC   HS-CAN3
  • GWM
Global clock message display   GWM   HS-CAN1
  • BCM
GPS data   APIM   HS-CAN3
  • GWM
GPS data   GWM   HS-CAN1
  • SOBDMC
GPS data   GWM   HS-CAN2
  • IPMA
GPS tracking request   TCU   HS-CAN4
  • GWM
GPS tracking request   GWM   HS-CAN3
  • APIM
Grill shutter position command   PCM   HS-CAN1
  • BCM
  • GWM
Grill shutter position command   GWM   HS-CAN3
  • IPC
Grill shutter position command   GWM   HS-CAN4
  • TCU
GSM gear message request (shift by wire)   GSM   HS-CAN2
  • GWM
GSM gear message request (shift by wire)   GWM   HS-CAN3
  • IPC
GSM gear message request (shift by wire)   GWM   HS-CAN4
  • TCU
GSM service required (shift by wire)   GSM   HS-CAN2
  • GWM
GSM service required (shift by wire)   GWM   HS-CAN3
  • IPC
GSM service required (shift by wire)   GWM   HS-CAN4
  • TCU
Headlamp flash-to-pass status   SCCM   HS-CAN2
  • IPMA
  • GWM
Headlamp flash-to-pass status   GWM   HS-CAN1
  • BCM
Headlamp high/low status   BCM   HS-CAN1
  • PCM
  • GWM
Headlamp high/low status   GWM   HS-CAN2
  • IPMA
  • SCCM
Headlamp high/low status   GWM   HS-CAN3
  • APIM
  • IPC
Headlamp high/low status   GWM   HS-CAN4
  • TCU
Headlamp low beam out   BCM   HS-CAN1
  • GWM
Headlamp low beam out   GWM   HS-CAN3
  • IPC
Headlamp low beam out   GWM   HS-CAN4
  • TCU
Headlamp on warning chime   BCM   HS-CAN1
  • GWM
Headlamp on warning chime   GWM   HS-CAN3
  • IPC
Headlamp on warning chime   GWM   HS-CAN4
  • TCU
Headlamp switch status   BCM   HS-CAN1
  • GWM
Headlamp switch status   GWM   HS-CAN2
  • IPMA
Headlamp switch status   GWM   HS-CAN4
  • TCU
Hill descent message request ABS module   HS-CAN2
  • GWM
Hill descent message request   GWM   HS-CAN3
  • IPC
Hill descent message request   GWM   HS-CAN4
  • TCU
Hill start assist status ABS module   HS-CAN2
  • GWM
Hill start assist status   GWM   HS-CAN1
  • PCM
Hill start assist status   GWM   HS-CAN3
  • IPC
Hill start assist status   GWM   HS-CAN4
  • TCU
Home safe lamp indicator request   BCM   HS-CAN1
  • GWM
Home safe lamp indicator request   GWM   HS-CAN3
  • IPC
Home safe lamp indicator request   GWM   HS-CAN4
  • TCU
Hood ajar status   BCM   HS-CAN1
  • GWM
Hood ajar status   GWM   HS-CAN2
  • ABS module
Hood ajar status   GWM   HS-CAN3
  • IPC
  • WACM
Hood ajar status   GWM   HS-CAN4
  • TCU
Horizon data   APIM   HS-CAN3
  • HUD module
  • GWM
Horizon data   GWM   HS-CAN2
  • IPMA
HUD adjustment menu request   IPC   HS-CAN3
  • HUD module
HUD brightness menu request   IPC   HS-CAN3
  • HUD module
HUD fault HUD module   HS-CAN3
  • IPC
  • GWM
HUD fault   GWM   HS-CAN2
  • IPMA
HUD fault   GWM   HS-CAN4
  • TCU
HUD flash command   IPMA   HS-CAN2
  • GWM
HUD flash command   GWM   HS-CAN3
  • HUD module
HUD flash command   GWM   HS-CAN4
  • TCU
HUD flash rate   IPMA   HS-CAN2
  • GWM
HUD flash rate   GWM   HS-CAN4
  • TCU
HUD menu request   IPC   HS-CAN3
  • HUD module
HUD settings active HUD module   HS-CAN2
  • IPMA
  • GWM
HUD settings active   GWM   HS-CAN3
  • IPC
HUD settings active   GWM   HS-CAN4
  • TCU
HVAC A/C request HVAC module   MS-CAN
  • GWM
HVAC A/C request   GWM   HS-CAN1
  • PCM
HVAC evaporator temperature request HVAC module   MS-CAN
  • GWM
HVAC evaporator temperature request   GWM   HS-CAN1
  • PCM
  • SOBDMC
HVAC front blower indicator HVAC module   MS-CAN
  • GWM
HVAC front blower indicator   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
HVAC front blower speed   APIM   HS-CAN3
  • GWM
HVAC front blower speed   GWM   MS-CAN
  • HVAC module
HVAC front blower status HVAC module   MS-CAN
  • RGTM
  • GWM
HVAC front blower status   GWM   HS-CAN1
  • BCM
  • PCM
HVAC rear blower status HVAC module   MS-CAN
  • GWM
HVAC rear blower status   GWM   HS-CAN1
  • BCM
  • PCM
  • SOBDMC
HVAC remote start request HVAC module   MS-CAN
  • GWM
HVAC remote start request   GWM   HS-CAN1
  • PCM
Ignition key type   BCM   HS-CAN1
  • PCM
  • GWM
Ignition key type   GWM   HS-CAN2
  • ABS module
  • IPMA
  • PAM
Ignition key type   GWM   HS-CAN3
  • APIM
  • ACM
  • DSP
  • IPC
Ignition key type   GWM   MS-CAN
  • SODL
  • SODR
Ignition key type   GWM   HS-CAN4
  • TCU
Ignition status   BCM   HS-CAN1
  • ACCM
  • AWD module
  • BCMC [ BJB ]
  • BECM
  • DCDC
  • PACM
  • PCM
  • SOBDM (Battery Charging Control Module [BCCM])
  • SOBDMC
  • GWM
Ignition status   GWM   HS-CAN2
  • ABS module
  • GSM
  • IPMA
  • OCS module
  • PAM
  • PSCM
  • RCM
Ignition status   GWM   HS-CAN3
  • ACM
  • APIM
  • DSP
  • HUD module
  • IPC
  • WACM
Ignition status   GWM   MS-CAN
  • DDM
  • DSM
  • HVAC module
  • PDM
  • RGTM
  • RTM
  • SODL
  • SODR
  • TRM
Ignition status   GWM   HS-CAN4
  • TCU
Illumination dimming level   BCM   HS-CAN1
  • GWM
Illumination dimming level   GWM   HS-CAN2
  • GSM
  • PAM
  • RCM
  • SCCM
Illumination dimming level   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
  • WACM
Illumination dimming level   GWM   MS-CAN
  • DDM
  • PDM
  • HVAC module
Illumination dimming level   GWM   HS-CAN4
  • TCU
Immobilizer message request   BCM   HS-CAN1
  • GWM
Immobilizer message request   GWM   HS-CAN3
  • IPC
Immobilizer message request   GWM   HS-CAN4
  • TCU
IPC chime request   IPC   HS-CAN3
  • ACM
  • DSP
IPC major units status   IPC   HS-CAN3
  • APIM
Key-in-ignition status   BCM   HS-CAN1
  • GWM
Key-in-ignition status   GWM   HS-CAN2
  • ABS module
  • GSM
Key-in-ignition status   GWM   HS-CAN3
  • APIM
  • DSP
  • IPC
  • WACM
Key-in-ignition status   GWM   HS-CAN4
  • TCU
Key-in-ignition status   GWM   MS-CAN
  • DSM
  • RTM
Key-in-ignition indicator status   BCM   HS-CAN1
  • GWM
Key-in-ignition indicator status   GWM   HS-CAN3
  • IPC
Key-in-ignition indicator status   GWM   HS-CAN4
  • TCU
Lane keep assist hands off   PSCM   HS-CAN2
  • IPMA
  • GWM
Lane keep assist hands off   GWM   HS-CAN3
  • IPC
Lane keep assist hands off   GWM   HS-CAN4
  • TCU
Lane keep assist reference angle request   IPMA   HS-CAN2
  • PSCM
  • GWM
Lane keep assist reference angle request   GWM   HS-CAN4
  • TCU
Lane keep assist switch position   SCCM   HS-CAN2
  • IPMA
  • GWM
Lane keep assist switch position   GWM   HS-CAN1
  • PCM
Lane keeping alert request   IPMA   HS-CAN2
  • PSCM
  • GWM
Lane keeping alert request   GWM   HS-CAN3
  • IPC
Lane keeping alert request   GWM   HS-CAN4
  • TCU
Lane keeping system available   PSCM   HS-CAN2
  • IPMA
  • GWM
Lane keeping system available   GWM   HS-CAN3
  • IPC
Lane keeping system available   GWM   HS-CAN4
  • TCU
Lane keeping system hands off display   IPMA   HS-CAN2
  • GWM
Lane keeping system hands off display   GWM   HS-CAN3
  • IPC
Lane keeping system hands off display   GWM   HS-CAN4
  • TCU
Lane keeping system status display   IPMA   HS-CAN2
  • GWM
Lane keeping system status display   GWM   HS-CAN3
  • HUD module
  • IPC
Lane keeping system status display   GWM   HS-CAN4
  • TCU
Language selection   IPC   HS-CAN3
  • ACM
  • APIM
  • HUD module
  • GWM
Language selection   GWM   HS-CAN4
  • TCU
Language update status   IPC   HS-CAN3
  • APIM
  • GWM
Language update status   GWM   HS-CAN4
  • TCU
Left rear door ajar status   BCM   HS-CAN1
  • GWM
Left rear door ajar status   GWM   HS-CAN2
  • ABS module
  • PAM
Left rear door ajar status   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
  • WACM
Left rear door ajar status   GWM   HS-CAN4
  • TCU
Left rear door ajar status   GWM   MS-CAN
  • DDM
  • HVAC module
  • PDM
  • RGTM
  • SODL
  • SODR
Left turn lamp on request   BCM   HS-CAN1
  • GWM
Left turn lamp on request   GWM   HS-CAN2
  • IPMA
  • SCCM
Left turn lamp on request   GWM   HS-CAN3
  • ACM
  • DSP
  • HUD module
  • IPC
  • WACM
Left turn lamp on request   GWM   HS-CAN4
  • TCU
Left turn lamp on request   GWM   MS-CAN
  • DDM
  • PDM
  • TRM
Left turn lamp on status   BCM   HS-CAN1
  • GWM
Left turn lamp on status   GWM   HS-CAN3
  • ACM
  • DSP
  • HUD module
  • IPC
  • WACM
Left turn lamp on status   GWM   HS-CAN4
  • TCU
Left turn lamp on status   GWM   MS-CAN
  • DDM
  • PDM
  • TRM
Liftgate ajar status   BCM   HS-CAN1
  • GWM
Liftgate ajar status   GWM   HS-CAN2
  • ABS module
  • SCCM
Liftgate ajar status   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
  • WACM
Liftgate ajar status   GWM   HS-CAN4
  • TCU
Liftgate ajar status   GWM   MS-CAN
  • HVAC module
Liftgate request   RGTM   MS-CAN
  • HVAC module
  • GWM
Liftgate request   GWM   HS-CAN1
  • BCM
  • PCM
Lock system message request   BCM   HS-CAN1
  • GWM
Lock system message request   GWM   HS-CAN3
  • IPC
Lock system message request   GWM   HS-CAN4
  • TCU
Low fuel warning indicator request   PCM   HS-CAN1
  • GWM
Low fuel warning indicator request   GWM   HS-CAN3
  • IPC
Manual mirror override   DDM   MS-CAN
  • DSM
Memory command   DSM   MS-CAN
  • DDM
  • PDM
  • GWM
Memory command   GWM   HS-CAN3
  • HUD module
  • IPC
Memory feedback request   DSM   MS-CAN
  • GWM
Memory feedback request   GWM   HS-CAN3
  • IPC
Memory seat switch request   DSM   MS-CAN
  • GWM
Memory seat switch request   GWM   HS-CAN1
  • BCM
Memory seat switch status   DDM   MS-CAN
  • DSM
Message center display   IPC   HS-CAN3
  • HUD module
  • GWM
Message center display   GWM   HS-CAN2
  • IPMA
  • SCCM
Message center display   GWM   HS-CAN1
  • BCM
Message center display   GWM   MS-CAN
  • DDM
  • PDM
  • DSM
  • HVAC module
Message center feature configuration   IPC   HS-CAN3
  • HUD module
  • GWM
Message center feature configuration   GWM   HS-CAN2
  • IPMA
  • SCCM
Message center feature configuration   GWM   HS-CAN1
  • BCM
Message center feature configuration   GWM   MS-CAN
  • DDM
  • PDM
  • DSM
  • HVAC module
Metric display   IPC   HS-CAN3
  • HUD module
MIL request   PCM   HS-CAN1
  • BCM
  • GWM
MIL request   GWM   HS-CAN2
  • RCM
MIL request   GWM   HS-CAN3
  • IPC
MIL request   GWM   HS-CAN4
  • TCU
Mirror heat on request HVAC module   MS-CAN
  • DDM
  • PDM
MyKey™ Belt-Minder™ audio mute   IPC   HS-CAN3
  • ACM
  • DSP
  • APIM
MyKey change key type request   IPC   HS-CAN3
  • GWM
MyKey change key type request   GWM   HS-CAN1
  • BCM
MyKey code status   BCM   HS-CAN1
  • GWM
MyKey code status   GWM   HS-CAN3
  • IPC
MyKey code status   GWM   HS-CAN4
  • TCU
MyKey volume limit status   DSP   HS-CAN3
  • APIM
Navigation status   APIM   HS-CAN3
  • HUD module
  • IPC
Neutral tow command   PCM   HS-CAN1
  • GWM
Neutral tow command   GWM   HS-CAN2
  • ABS module
  • GSM
  • PAM
Neutral tow command   GWM   HS-CAN4
  • TCU
OCS sensor data OCS module   HS-CAN2
  • RCM
  • GWM
OCS sensor data   GWM   HS-CAN4
  • TCU
OCS serial number OCS module   HS-CAN2
  • RCM
  • GWM
OCS serial number   GWM   HS-CAN4
  • TCU
OCS vehicle calibration data OCS module   HS-CAN2
  • RCM
  • GWM
OCS vehicle calibration data   GWM   HS-CAN4
  • TCU
Odometer count   PCM   HS-CAN1
  • GWM
Odometer count   GWM   HS-CAN3
  • IPC
  • APIM
Odometer count   GWM   HS-CAN4
  • TCU
Odometer master value   IPC   HS-CAN3
  • APIM
  • GWM
Odometer master value   GWM   HS-CAN2
  • ABS module
  • RCM
  • PSCM
  • IPMA
Odometer master value   GWM   HS-CAN1
  • ACCM
  • AWD module
  • BCM
  • BECM
  • PCM
  • SOBDM (Battery Charging Control Module [BCCM])
  • SOBDMC
Odometer master value   GWM   HS-CAN4
  • TCU
Odometer master value   GWM   MS-CAN
  • RGTM
Odometer trip programming data   IPC   HS-CAN3
  • GWM
Odometer trip programming data   GWM   HS-CAN1
  • PCM
Odometer trip programming data   GWM   HS-CAN4
  • TCU
Oil pressure warning indicator request   PCM   HS-CAN1
  • GWM
Oil pressure warning indicator request   GWM   HS-CAN3
  • IPC
Oil pressure warning indicator request   GWM   HS-CAN4
  • TCU
Outside air temperature HVAC module   MS-CAN
  • DDM
  • PDM
  • RGTM
  • GWM
Outside air temperature   GWM   HS-CAN1
  • PCM
Outside air temperature   GWM   HS-CAN2
  • IPMA
  • PAM
  • PSCM
Outside air temperature   GWM   HS-CAN3
  • APIM
  • DSP
  • HUD module
  • IPC
Park brake active request (shift by wire)   GSM   HS-CAN2
  • ABS module
  • GWM
Park brake active request (shift by wire)   GWM   HS-CAN4
  • TCU
Park brake active-trans gear (shift by wire)   PCM   HS-CAN1
  • GWM
Park brake active-trans gear (shift by wire)   GWM   HS-CAN2
  • ABS module
  • GSM
Park brake active-trans gear (shift by wire)   GWM   HS-CAN4
  • TCU
Parking aid chime request   PAM   HS-CAN2
  • GWM
Parking aid chime request   GWM   HS-CAN3
  • APIM
  • IPC
Parking aid chime request   GWM   HS-CAN4
  • TCU
Parking aid fault status   PAM   HS-CAN2
  • GWM
Parking aid fault status   GWM   HS-CAN3
  • APIM
  • IPC
Parking aid fault status   GWM   HS-CAN1
  • BCM
Parking aid fault status   GWM   HS-CAN4
  • TCU
Parking aid front status   PAM   HS-CAN2
  • GWM
Parking aid front status   GWM   HS-CAN3
  • APIM
  • IPC
Parking aid front status   GWM   HS-CAN1
  • BCM
Parking aid front status   GWM   HS-CAN4
  • TCU
Parking aid lamp request   PAM   HS-CAN2
  • GWM
Parking aid lamp request   GWM   HS-CAN4
  • TCU
Parking aid rear status   PAM   HS-CAN2
  • GWM
Parking aid rear status   GWM   HS-CAN3
  • APIM
  • IPC
Parking aid rear status   GWM   HS-CAN4
  • TCU
Parking aid sensor data   PAM   HS-CAN2
  • GWM
Parking aid sensor data   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
Parking aid sensor data   GWM   HS-CAN4
  • TCU
Parking aid text message request   PAM   HS-CAN2
  • GWM
Parking aid text message request   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
Parking aid text message request   GWM   HS-CAN4
  • TCU
Parking brake (red) indicator request ABS module   HS-CAN2
  • GWM
Parking brake (red) indicator request   GWM   HS-CAN3
  • IPC
Parking brake (red) indicator request   GWM   HS-CAN4
  • TCU
Parking brake active status   BCM   HS-CAN1
  • AWD module
  • PCM
  • GWM
Parking brake active status   GWM   HS-CAN2
  • ABS module
Parking brake active status   GWM   HS-CAN3
  • APIM
  • IPC
  • WACM
Parking brake active status   GWM   HS-CAN4
  • TCU
Parking brake active status   GWM   MS-CAN
  • SODL
  • SODR
Parking brake chime request   BCM   HS-CAN1
  • GWM
Parking brake chime request   GWM   HS-CAN3
  • IPC
Parking brake chime request   GWM   HS-CAN4
  • TCU
Parking brake status ABS module   HS-CAN2
  • GSM
  • IPMA
  • PAM
  • GWM
Parking brake status   GWM   HS-CAN1
  • AWD module
  • BCM
  • PCM
  • SOBDMC
Parking brake status   GWM   HS-CAN3
  • APIM
Parking brake status   GWM   HS-CAN4
  • TCU
Parking brake status   GWM   MS-CAN
  • HVAC module
Parklamp status   BCM   HS-CAN1
  • GWM
Parklamp status   GWM   HS-CAN2
  • GSM
  • PAM
Parklamp status   GWM   HS-CAN3
  • ACM
  • APIM
  • IPC
  • WACM
Parklamp status   GWM   MS-CAN
  • DDM
  • PDM
  • HVAC module
  • SODL
  • SODR
  • TRM
Parklamp status   GWM   HS-CAN4
  • TCU
Park light status   BCM   HS-CAN1
  • GWM
Park light status   GWM   HS-CAN4
  • TCU
Park light status   GWM   MS-CAN
  • TRM
Park lock control enabled   BCM   HS-CAN1
  • GWM
Park lock control enabled   GWM   HS-CAN2
  • GSM
Park lock control enabled   GWM   HS-CAN3
  • IPC
Park lock control enabled   GWM   HS-CAN4
  • TCU
Passenger door ajar status   BCM   HS-CAN1
  • GWM
Passenger door ajar status   GWM   HS-CAN2
  • ABS module
  • PAM
Passenger door ajar status   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
  • WACM
Passenger door ajar status   GWM   HS-CAN4
  • TCU
Passenger door ajar status   GWM   MS-CAN
  • DDM
  • PDM
  • DSM
  • HVAC module
  • RGTM
  • SODL
  • SODR
Passenger door lock switch status   PDM   MS-CAN
  • GWM
Passenger door lock switch status   GWM   HS-CAN1
  • BCM
Passenger seat belt buckle status   RCM   HS-CAN2
  • OCS module
  • GWM
Passenger seat belt buckle status   GWM   HS-CAN3
  • APIM
  • IPC
Passenger seat belt buckle status   GWM   HS-CAN4
  • TCU
PATS control command   BCM   HS-CAN1
  • PCM
  • GWM
PATS control command   GWM   HS-CAN4
  • TCU
PATS target status   PCM   HS-CAN1
  • BCM
  • GWM
PATS target status   GWM   HS-CAN2
  • ABS module
PATS target status   GWM   HS-CAN4
  • TCU
Perimeter alarm chime request   BCM   HS-CAN1
  • GWM
Perimeter alarm chime request   GWM   HS-CAN3
  • IPC
Perimeter alarm chime request   GWM   HS-CAN4
  • TCU
Perimeter alarm event status   BCM   HS-CAN1
  • GWM
Perimeter alarm event status   GWM   HS-CAN4
  • TCU
Perimeter alarm status   BCM   HS-CAN1
  • BCMC [ BJB ]
  • GWM
Perimeter alarm status   GWM   HS-CAN3
  • IPC
Perimeter alarm status   GWM   HS-CAN4
  • TCU
Perimeter alarm status   GWM   MS-CAN
  • TRM
Power liftgate chime request   RGTM   MS-CAN
  • GWM
Power liftgate chime request   GWM   HS-CAN3
  • IPC
Power liftgate request   BCM   HS-CAN1
  • GWM
Power liftgate request   GWM   HS-CAN4
  • TCU
Power liftgate request   GWM   MS-CAN
  • RGTM
Power pack torque status   PCM   HS-CAN1
  • ACCM
  • AWD module
  • BCM
  • BCMC [ BJB ]
  • BECM
  • DCDC
  • PACM
  • SOBDM (Battery Charging Control Module [BCCM])
  • GWM
Power pack torque status   GWM   HS-CAN2
  • ABS module
  • IPMA
  • PSCM
  • SCCM
  • OCS module
  • GSM
  • PAM
Power pack torque status   GWM   HS-CAN3
  • ACM
  • APIM
  • DSP
  • HUD module
  • IPC
  • WACM
Power pack torque status   GWM   HS-CAN4
  • TCU
Power pack torque status   GWM   MS-CAN
  • DDM
  • PDM
  • DSM
  • HVAC module
  • RGTM
  • RTM
  • TRM
Power shed level request   BCM   HS-CAN1
  • PCM
  • GWM
Power shed level request   GWM   HS-CAN2
  • GSM
  • PAM
  • SCCM
Power shed level request   GWM   MS-CAN
  • DDM
  • PDM
  • HVAC module
  • TRM
Power shed level request   GWM   HS-CAN3
  • IPC
  • APIM
Power shed level request   GWM   HS-CAN4
  • TCU
Powertrain drive mode select request ABS module   HS-CAN2
  • GWM
Powertrain drive mode select request   GWM   HS-CAN1
  • PCM
Powertrain drive mode select request   GWM   MS-CAN
  • HVAC module
Powertrain drive mode selection status   PCM   HS-CAN1
  • GWM
Powertrain drive mode selection status   GWM   HS-CAN2
  • ABS module
Powertrain drive mode selection status   GWM   HS-CAN3
  • IPC
Powertrain drive mode selection status   GWM   HS-CAN4
  • TCU
Puddle lamp activation   BCM   HS-CAN1
  • GWM
Puddle lamp activation   GWM   HS-CAN3
  • HUD module
Puddle lamp activation   GWM   HS-CAN4
  • TCU
Puddle lamp activation   GWM   MS-CAN
  • DDM
  • PDM
RCM serial number   RCM   HS-CAN2
  • ABS module
  • OCS module
Rear camera on demand request   BCM   HS-CAN1
  • GWM
Rear camera on demand request   GWM   MS-CAN
  • TRM
Rear camera on demand request   GWM   HS-CAN3
  • APIM
Reduced guard status   BCM   HS-CAN1
  • GWM
Reduced guard status   GWM   HS-CAN3
  • IPC
Reduced guard status   GWM   HS-CAN4
  • TCU
Remote start quiet mode HVAC module   MS-CAN
  • GWM
Remote start quiet mode   GWM   HS-CAN1
  • BCM
Remote start status   BCM   HS-CAN1
  • BCMC [ BJB ]
  • GWM
Remote start status   GWM   HS-CAN3
  • APIM
  • IPC
  • WACM
Remote start status   GWM   HS-CAN4
  • TCU
Restraint impact event status   RCM   HS-CAN2
  • ABS module
  • IPMA
  • OCS module
  • SCCM
  • GWM
Restraint impact event status   GWM   HS-CAN1
  • ACCM
  • BCM
  • BECM
  • PCM
  • SOBDMC
Restraint impact event status   GWM   HS-CAN4
  • TCU
Restraint impact event status   GWM   MS-CAN
  • HVAC module
  • SODL
  • SODR
Restraint module power fault   BCM   HS-CAN1
  • GWM
Restraint module power fault   GWM   HS-CAN2
  • RCM
Restraint module power fault   GWM   HS-CAN4
  • TCU
Restraints indicator status   IPC   HS-CAN3
  • GWM
Restraints indicator status   GWM   HS-CAN2
  • RCM
Reverse gear state   PCM   HS-CAN1
  • BCM
  • PACM
  • GWM
Reverse gear state   GWM   HS-CAN2
  • ABS module
  • IPMA
  • OCS module
  • PSCM
  • RCM
  • SCCM
Reverse gear state   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
Reverse gear state   GWM   HS-CAN4
  • TCU
Reverse gear state   GWM   MS-CAN
  • DDM
  • PDM
  • SODL
  • SODR
  • TRM
Reverse mirror chime request   DDM   MS-CAN
  • DSM
  • GWM
Reverse mirror chime request   GWM   HS-CAN3
  • IPC
Right rear door ajar status   BCM   HS-CAN1
  • GWM
Right rear door ajar status   GWM   HS-CAN2
  • ABS module
  • PAM
Right rear door ajar status   GWM   HS-CAN3
  • APIM
  • HUD module
  • IPC
Right rear door ajar status   GWM   HS-CAN4
  • TCU
Right turn lamp on request   BCM   HS-CAN1
  • GWM
Right turn lamp on request   GWM   HS-CAN2
  • IPMA
  • SCCM
Right turn lamp on request   GWM   HS-CAN3
  • ACM
  • DSP
  • HUD module
  • IPC
Right turn lamp on request   GWM   HS-CAN4
  • TCU
Right turn lamp on request   GWM   MS-CAN
  • DDM
  • PDM
  • TRM
Right turn lamp on status   BCM   HS-CAN1
  • GWM
Right turn lamp on status   GWM   HS-CAN2
  • IPMA
  • SCCM
Right turn lamp on status   GWM   HS-CAN4
  • TCU
Right turn lamp on status   GWM   MS-CAN
  • DDM
  • PDM
  • TRM
Road curvature   IPMA   HS-CAN2
  • PSCM
  • GWM
Road curvature   GWM   HS-CAN4
  • TCU
Satellite radio alert status   APIM   HS-CAN3
  • ACM
Satellite radio request   APIM   HS-CAN3
  • ACM
Second row seat belt buckle status   RCM   HS-CAN2
  • GWM
Second row seat belt buckle status   GWM   HS-CAN3
  • IPC
Selectable drive mode message display ABS module   HS-CAN2
  • GWM
Selectable drive mode message display   GWM   HS-CAN1
  • PCM
Selectable drive mode message display   GWM   HS-CAN3
  • IPC
Selectable drive mode request ABS module   HS-CAN2
  • GWM
Selectable drive mode request   GWM   HS-CAN1
  • PCM
Selectable drive mode request   GWM   HS-CAN3
  • IPC
Selectable drive mode request   GWM   MS-CAN
  • HVAC module
Selectable drive mode status ABS module   HS-CAN2
  • GWM
Selectable drive mode status   GWM   HS-CAN3
  • IPC
Side detect left illumination   SODL   MS-CAN
  • DDM
  • PDM
  • GWM
Side detect left illumination   GWM   HS-CAN3
  • IPC
Side detect right illumination   SODR   MS-CAN
  • DDM
  • PDM
  • GWM
Side detect right illumination   GWM   HS-CAN3
  • IPC
Side obstacle detect status-left   SODL   MS-CAN
  • SODR
  • GWM
Side obstacle detect status-left   GWM   HS-CAN3
  • IPC
Side obstacle detect status-right   SODR   MS-CAN
  • SODL
  • GWM
Side obstacle detect status-right   GWM   HS-CAN3
  • IPC
Side obstacle display warning indicator   IPC   HS-CAN3
  • GWM
Side obstacle display warning indicator   GWM   MS-CAN
  • SODL
  • SODR
Side obstacle sensor status-left   SODL   MS-CAN
  • DDM
  • PDM
  • SODR
  • GWM
Side obstacle sensor status-left   GWM   HS-CAN2
  • PAM
Side obstacle sensor status-left   GWM   HS-CAN3
  • IPC
Side obstacle sensor status-right   SODR   MS-CAN
  • DDM
  • PDM
  • SODL
  • GWM
Side obstacle sensor status-right   GWM   HS-CAN2
  • PAM
Side obstacle sensor status-right   GWM   HS-CAN3
  • IPC
Stability-traction control chime request ABS module   HS-CAN2
  • GWM
Stability-traction control chime request   GWM   HS-CAN3
  • IPC
Stability-traction control chime request   GWM   HS-CAN4
  • TCU
Stability-traction control disabled indicator request ABS module   HS-CAN2
  • IPMA
  • PAM
  • RCM
  • GWM
Stability-traction control disabled indicator request   GWM   HS-CAN1
  • AWD module
  • PCM
Stability-traction control disabled indicator request   GWM   HS-CAN3
  • IPC
Stability-traction control disabled indicator request   GWM   HS-CAN4
  • TCU
Stability-traction control event in progress ABS module   HS-CAN2
  • IPMA
  • PAM
  • PSCM
  • RCM
Stability-traction control event in progress   GWM   HS-CAN1
  • AWD module
  • PCM
Stability-traction control event in progress   GWM   HS-CAN3
  • APIM
Stability-traction control event in progress   GWM   HS-CAN4
  • TCU
Stability-traction control indicator request ABS module   HS-CAN2
  • RCM
  • IPMA
  • PAM
  • GWM
Stability-traction control indicator request   GWM   HS-CAN1
  • PCM
Stability-traction control indicator request   GWM   HS-CAN3
  • IPC
Stability-traction control indicator request   GWM   HS-CAN4
  • TCU
Stability-traction control on/off message request ABS module   HS-CAN2
  • GWM
Stability-traction control on/off message request   GWM   HS-CAN3
  • IPC
Starting system message request   PCM   HS-CAN1
  • GWM
Starting system message request   GWM   HS-CAN3
  • IPC
Starting system message request   GWM   HS-CAN4
  • TCU
Steering column position switch status   SCCM   HS-CAN2
  • GWM
Steering column position switch status   GWM   MS-CAN
  • DSM
Steering effort status   PSCM   HS-CAN2
  • GWM
Steering effort status   GWM   HS-CAN1
  • BCM
Steering effort status   GWM   HS-CAN4
  • TCU
Steering wheel angle ABS module   HS-CAN2
  • IPMA
  • PSCM
  • RCM
  • SCCM
  • PAM
  • GWM
Steering wheel angle   GWM   HS-CAN1
  • BCM
  • PCM
  • AWD module
Steering wheel angle   GWM   HS-CAN3
  • APIM
  • IPC
Steering wheel heat request HVAC module   MS-CAN
  • GWM
Steering wheel heat request   GWM   HS-CAN2
  • SCCM
Steering wheel lock message request   BCM   HS-CAN1
  • GWM
Steering wheel lock message request   GWM   HS-CAN3
  • IPC
Steering wheel lock message request   GWM   HS-CAN4
  • TCU
Steering wheel message center switch data   SCCM   HS-CAN2
  • GWM
Steering wheel message center switch data   GWM   HS-CAN3
  • HUD module
  • IPC
Stop lamp brake request ABS module   HS-CAN2
  • GWM
Stop lamp brake request   GWM   HS-CAN1
  • BCM
Stop lamp brake request   GWM   HS-CAN4
  • TCU
Stop lamp request   BCM   HS-CAN1
  • GWM
Stop lamp request   GWM   HS-CAN3
  • IPC
Stop lamp request   GWM   HS-CAN4
  • TCU
Stop lamp request   GWM   MS-CAN
  • TRM
Stop/start drive mode indicator   PCM   HS-CAN1
  • BCM
  • GWM
Stop/start drive mode indicator   GWM   HS-CAN3
  • IPC
Stop/start drive mode indicator   GWM   HS-CAN4
  • TCU
Stop/start drive mode indicator   GWM   MS-CAN
  • HVAC module
Stop/start drive mode request   APIM   HS-CAN3
  • GWM
Stop/start drive mode request   GWM   HS-CAN1
  • PCM
Stop/start drive mode request   GWM   HS-CAN4
  • TCU
Stop/start message request   PCM   HS-CAN1
  • GWM
Stop/start message request   GWM   HS-CAN3
  • IPC
Stop/start message request   GWM   HS-CAN4
  • TCU
Stop/start mode request   IPC   HS-CAN3
  • GWM
Stop/start mode request   GWM   HS-CAN1
  • PCM
Stop/start standby indicator   PCM   HS-CAN1
  • GWM
Stop/start standby indicator   GWM   MS-CAN
  • HVAC module
Stop/start standby indicator   GWM   HS-CAN3
  • IPC
Stop/start standby indicator   GWM   HS-CAN4
  • TCU
SYNC alerts   APIM   HS-CAN3
  • ACM
  • DSP
  • GWM
SYNC alerts   GWM   HS-CAN4
  • TCU
TCU activation request   APIM   HS-CAN3
  • GWM
TCU activation request   GWM   HS-CAN4
  • TCU
TCU activation status   TCU   HS-CAN4
  • GWM
TCU activation status   GWM   HS-CAN3
  • APIM
Telematics factory reset TCU module   HS-CAN4
  • GWM
Telematics factory reset   GWM   HS-CAN3
  • APIM
Telematics service contract status TCU module   HS-CAN4
  • GWM
Telematics service contract status   GWM   HS-CAN1
  • SOBDMC
Telematics service contract status   GWM   HS-CAN3
  • APIM
Temperature unit selection   IPC   HS-CAN3
  • APIM
  • HUD module
  • GWM
Temperature unit selection   GWM   MS-CAN
  • HVAC module
Tire pressure data   BCM   HS-CAN1
  • GWM
Tire pressure data   GWM   HS-CAN3
  • IPC
  • APIM
Tire pressure data   GWM   HS-CAN4
  • TCU
Tire pressure data   GWM   MS-CAN
  • RTM
Tire pressure information   BCM   HS-CAN1
  • GWM
Tire pressure information   GWM   MS-CAN
  • RTM
Tire pressure information   GWM   HS-CAN4
  • TCU
Tire pressure placard data   BCM   HS-CAN1
  • GWM
Tire pressure placard data   GWM   HS-CAN3
  • IPC
  • APIM
Tire pressure placard data   GWM   HS-CAN4
  • TCU
Tire pressure reset request   IPC   HS-CAN3
  • GWM
Tire pressure reset request   GWM   HS-CAN1
  • BCM
Tire pressure reset request   GWM   HS-CAN4
  • TCU
Tire pressure system status   BCM   HS-CAN1
  • GWM
Tire pressure system status   GWM   MS-CAN
  • RTM
Tire pressure system status   GWM   HS-CAN3
  • IPC
  • APIM
Tire pressure system status   GWM   HS-CAN4
  • TCU
Tire pressure warning indicator   BCM   HS-CAN1
  • GWM
Tire pressure warning indicator   GWM   HS-CAN3
  • IPC
  • APIM
Tire pressure warning indicator   GWM   MS-CAN
  • RTM
Tire pressure warning indicator   GWM   HS-CAN4
  • TCU
Traction control indicator off request ABS module   HS-CAN2
  • GWM
Traction control indicator off request   GWM   HS-CAN3
  • IPC
Traffic jam assist message display   IPMA   HS-CAN2
  • GWM
Traffic jam assist message display   GWM   HS-CAN3
  • HUD module
  • IPC
Traffic jam assist message display   GWM   HS-CAN4
  • TCU
Traffic jam assist warning indicator   IPMA   HS-CAN2
  • GWM
Traffic jam assist warning indicator   GWM   HS-CAN3
  • HUD module
  • IPC
Traffic jam assist warning indicator   GWM   HS-CAN4
  • TCU
Trailer battery charge   TRM   MS-CAN
  • GWM
Trailer battery charge   GWM   HS-CAN3
  • IPC
Trailer lamp connected   TRM   MS-CAN
  • SODL
  • SODR
  • GWM
Trailer lamp connected   GWM   HS-CAN1
  • AWD module
  • PCM
  • BCM
Trailer lamp connected   GWM   HS-CAN2
  • ABS module
  • IPMA
  • PAM
Trailer lamp connected   GWM   HS-CAN3
  • APIM
  • IPC
Trailer lamp out   TRM   MS-CAN
  • GWM
Trailer lamp out   GWM   HS-CAN3
  • IPC
Trailer sway event in progress ABS module   HS-CAN2
  • GWM
Trailer sway event in progress   GWM   HS-CAN3
  • IPC
Trailer sway event in progress   GWM   HS-CAN4
  • TCU
Trailer turn lamp status   TRM   MS-CAN
  • GWM
Trailer turn lamp status   GWM   HS-CAN1
  • BCM
Transmission gear button request   GSM   HS-CAN2
  • GWM
Transmission gear button request   GWM   HS-CAN1
  • PCM
Transmission gear button request   GWM   HS-CAN4
  • TCU
Transmission gear command status   PCM   HS-CAN1
  • GWM
Transmission gear command status   GWM   HS-CAN2
  • GSM
Transmission gear command status   GWM   HS-CAN4
  • TCU
Transmission gear display   PCM   HS-CAN1
  • GWM
Transmission gear display   GWM   HS-CAN3
  • HUD module
  • IPC
Transmission gear display   GWM   HS-CAN4
  • TCU
Transmission gear display mode   PCM   HS-CAN1
  • GWM
Transmission gear display mode   GWM   HS-CAN2
  • GSM
Transmission gear display mode   GWM   HS-CAN3
  • HUD module
  • IPC
Transmission gear display mode   GWM   HS-CAN4
  • TCU
Transmission gear message request   PCM   HS-CAN1
  • GWM
Transmission gear message request   GWM   HS-CAN3
  • IPC
Transmission gear message request   GWM   HS-CAN4
  • TCU
Transmission gear request   GSM   HS-CAN2
  • GWM
Transmission gear request   GWM   HS-CAN1
  • BCM
  • PCM
  • SOBDMC
Transmission gear request   GWM   HS-CAN4
  • TCU
Transmission not in park indicator request   BCM   HS-CAN1
  • GWM
Transmission not in park indicator request   GWM   HS-CAN3
  • IPC
Transmission not in park indicator request   GWM   HS-CAN4
  • TCU
Transmission range display (shift by wire)   GSM   HS-CAN2
  • GWM
Transmission range display (shift by wire)   GWM   HS-CAN1
  • PCM
Transmission range display (shift by wire)   GWM   HS-CAN4
  • TCU
Transmission range request   PCM   HS-CAN1
  • GWM
Transmission range request   GWM   HS-CAN2
  • ABS module
  • GSM
  • PAM
Transmission range request   GWM   HS-CAN4
  • TCU
Transmission service required   PCM   HS-CAN1
  • GWM
Transmission service required   GWM   HS-CAN2
  • RCM
Transmission service required   GWM   HS-CAN3
  • IPC
Transmission service required   GWM   HS-CAN4
  • TCU
Transport mode   BCM   HS-CAN1
  • AWD module
  • BCMC [ BJB ]
  • PACM
  • PCM
  • SOBDM (Battery Charging Control Module [BCCM])
  • SOBDMC
  • GWM
Transport mode   GWM   HS-CAN3
  • ACM
  • APIM
  • DSP
  • HUD module
  • IPC
Transport mode   GWM   HS-CAN4
  • TCU
Trip odometer verify   PCM   HS-CAN1
  • GWM
Trip odometer verify   GWM   HS-CAN3
  • IPC
Trip unit selection   IPC   HS-CAN3
  • APIM
  • HUD module
Turn signal switch status   SCCM   HS-CAN2
  • IPMA
  • PAM
  • PSCM
  • GWM
Turn signal switch status   GWM   HS-CAN1
  • BCM
Turn signal switch status   GWM   HS-CAN3
  • APIM
  • IPC
Turn signal switch status   GWM   MS-CAN
  • SODL
  • SODR
Turn signal switch status   GWM   HS-CAN4
  • TCU
Valet mode status   APIM   HS-CAN3
  • GWM
Valet mode status   GWM   HS-CAN1
  • BCM
Valet mode status   GWM   HS-CAN4
  • TCU
Valet mode status   GWM   MS-CAN
  • DSM
Vehicle configuration data   BCM   HS-CAN1
  • ACCM
  • AWD module
  • BECM
  • DCDC
  • PCM
  • SOBDM (Battery Charging Control Module [BCCM])
  • SOBDMC
  • GWM
Vehicle configuration data   GWM   HS-CAN2
  • ABS module
  • GSM
  • IPMA
  • PAM
  • OCS module
  • PSCM
  • RCM
  • SCCM
Vehicle configuration data   GWM   MS-CAN
  • DDM
  • PDM
  • HVAC module
  • SODL
  • SODR
  • TRM
  • RGTM
  • RTM
Vehicle configuration data   GWM   HS-CAN3
  • ACM
  • APIM
  • HUD module
  • IPC
Vehicle configuration data   GWM   HS-CAN4
  • TCU
Vehicle lateral acceleration ABS module   HS-CAN2
  • PSCM
  • GWM
Vehicle lateral acceleration   GWM   HS-CAN1
  • AWD module
  • PCM
Vehicle lateral acceleration   GWM   HS-CAN3
  • IPC
Vehicle lateral acceleration   GWM   HS-CAN4
  • TCU
Vehicle lateral acceleration   GWM   MS-CAN
  • RGTM
Vehicle lateral acceleration 2   RCM   HS-CAN2
  • ABS module
  • IPMA
  • GWM
Vehicle lateral acceleration 2   GWM   HS-CAN1
  • AWD module
Vehicle longitudinal acceleration ABS module   HS-CAN2
  • GWM
Vehicle longitudinal acceleration   GWM   HS-CAN1
  • AWD module
  • PCM
Vehicle longitudinal acceleration   GWM   HS-CAN3
  • IPC
Vehicle longitudinal acceleration   GWM   HS-CAN4
  • TCU
Vehicle longitudinal acceleration   GWM   MS-CAN
  • RGTM
Vehicle longitudinal acceleration 2   RCM   HS-CAN2
  • IPMA
  • ABS module
  • GWM
Vehicle longitudinal acceleration 2   GWM   HS-CAN1
  • AWD module
Vehicle lock requestor   BCM   HS-CAN1
  • GWM
Vehicle lock requestor   GWM   MS-CAN
  • DDM
  • PDM
  • HVAC module
Vehicle lock requestor   GWM   HS-CAN2
  • GSM
Vehicle lock requestor   GWM   HS-CAN3
  • HUD module
Vehicle lock requestor   GWM   HS-CAN4
  • TCU
Vehicle lock status   BCM   HS-CAN1
  • GWM
Vehicle lock status   GWM   MS-CAN
  • DDM
  • PDM
  • HVAC module
  • RGTM
Vehicle lock status   GWM   HS-CAN2
  • GSM
Vehicle lock status   GWM   HS-CAN3
  • ACM
  • APIM
  • HUD module
  • IPC
Vehicle lock status   GWM   HS-CAN4
  • TCU
Vehicle pitch angle display ABS module   HS-CAN2
  • GWM
Vehicle pitch angle display   GWM   HS-CAN3
  • IPC
Vehicle pitch angle display   GWM   HS-CAN4
  • TCU
Vehicle roll angle display ABS module   HS-CAN2
  • GWM
Vehicle roll angle display   GWM   HS-CAN3
  • IPC
Vehicle roll angle display   GWM   HS-CAN4
  • TCU
Vehicle speed   PCM   HS-CAN1
  • AWD module
  • BCM
  • BCMC [ BJB ]
  • BECM
  • PACM
  • SOBDMC
  • GWM
Vehicle speed   GWM   HS-CAN3
  • DSP
  • IPC
  • ACM
  • APIM
Vehicle speed   GWM   HS-CAN2
  • RCM
  • SCCM
  • IPMA
  • GSM
  • PAM
  • OCS module
Vehicle speed   GWM   HS-CAN4
  • TCU
Vehicle speed display   IPC   HS-CAN3
  • HUD module
Vehicle speed display   GWM   HS-CAN4
  • TCU
Vehicle temperature display units   APIM   HS-CAN3
  • IPC
Vehicle trip display units   APIM   HS-CAN3
  • IPC
Vehicle yaw rate ABS module   HS-CAN2
  • IPMA
  • PAM
  • PSCM
  • GWM
Vehicle yaw rate   RCM   HS-CAN2
  • ABS module
  • IPMA
  • PSCM
  • GWM
Vehicle yaw rate   GWM   HS-CAN1
  • AWD module
  • PCM
  • SOBDMC
Vehicle yaw rate   GWM   HS-CAN3
  • ACM
  • APIM
Vehicle yaw rate   GWM   MS-CAN
  • SODL
  • SODR
Vehicle yaw rate   GWM   HS-CAN4
  • TCU
Voice recognition audio source request   APIM   HS-CAN3
  • ACM
  • GWM
Voice recognition audio source request   GWM   HS-CAN4
  • TCU
Voice recognition bluetooth response data   APIM   HS-CAN3
  • HUD module
  • IPC
Voice recognition status   APIM   HS-CAN3
  • ACM
  • HUD module
  • IPC
Wheel rotation count ABS module   HS-CAN2
  • PAM
  • GWM
Wheel rotation count   GWM   HS-CAN1
  • BCM
Wheel rotation count   GWM   MS-CAN
  • SODL
  • SODR
Wheel rotation count   GWM   HS-CAN3
  • ACM
  • APIM
Wheel rotation count   GWM   HS-CAN4
  • TCU
Wheel rotation direction ABS module   HS-CAN2
  • PAM
  • PSCM
  • IPMA
  • GWM
Wheel rotation direction   GWM   HS-CAN1
  • PCM
Wheel rotation direction   GWM   HS-CAN3
  • ACM
  • APIM
Wheel rotation direction   GWM   HS-CAN4
  • TCU
Wheel rotation direction   GWM   MS-CAN
  • SODL
  • SODR
Wheel speed data ABS module   HS-CAN2
  • PSCM
  • IPMA
  • PAM
  • GWM
Wheel speed data   GWM   HS-CAN1
  • AWD module
  • PCM
Wheel speed data   GWM   HS-CAN4
  • TCU
Wheel torque   PCM   HS-CAN1
  • AWD module
  • GWM
Wheel torque   GWM   HS-CAN2
  • ABS module
  • PSCM
  • RCM
  • GWM
Wheel torque   GWM   HS-CAN3
  • IPC
Wheel torque   GWM   HS-CAN4
  • TCU
WiFi hot spot status   TCU   HS-CAN4
  • GWM
WiFi hot spot status   GWM   HS-CAN3
  • APIM
Window global open command   BCM   HS-CAN1
  • GWM
Window global open command   GWM   HS-CAN4
  • TCU
Window global open command   GWM   MS-CAN
  • DDM
  • PDM
Window lockout status   BCM   HS-CAN1
  • GWM
Window lockout status   GWM   HS-CAN4
  • TCU
Window lockout status   GWM   MS-CAN
  • DDM
Wiper front status   SCCM   HS-CAN2
  • IPMA
  • GWM
Wiper front status   GWM   MS-CAN
  • HVAC module
  • SODL
  • SODR
Wiper front status   GWM   HS-CAN3
  • ACM
  • APIM
  • HUD module
Wiper front status   GWM   HS-CAN1
  • AWD module
  • BCM
  • PCM
Wiper front status   GWM   HS-CAN4
  • TCU

    Description and Operation - Communications Network - Overview

    Overview Multiplexing is a method of sending 2 or more signals simultaneously over a single circuit. Multiplexing allows 2 or more electronic modules (nodes) to communicate over a twisted wire pair [data (+) and data (-)] network...

    Diagnosis and Testing - Communications Network

    Diagnostic Trouble Code (DTC) Chart Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices. REFER to: Diagnostic Methods (100-00 General Information, Description and Operation)...

    Other information:

    Ford Escape 2020-2024 Service Manual: Description and Operation - Message Center - System Operation and Component Description


    System Operation System Diagram Item Description 1 GWM 2 RH steering wheel switch 3 PSCM 4 BCM 5 Door/liftgate ajar switches 6 SODR 7 Fuel pump and sender unit 8 IPC 9 APIM 10 Washer fluid level switch 11 Message center display 12 PCM 13 Engine oil pressure sensor..

    Ford Escape 2020-2024 Owners Manual: Engine Oil Capacity and Specification - 2.0L EcoBoost™


    Use oil that meets the defined specification and viscosity grade. If you do not use oil that meets the defined specification and viscosity grade, it could result in: Component damage that your vehicle warranty does not cover. Longer engine cranking periods. Increased emission levels. Reduced vehicle performance. Reduced fuel economy. An oil that displays this symbol conforms to curre..

    Categories

    Vehicle Identification

    Locating the Vehicle Identification Number

    The vehicle identification number is on the left-hand side of the instrument panel.

    Ford Escape. Vehicle Identification

    read more

    Copyright © 2024 www.fordescape4.com
