Ford Escape: Climate Control System - General Information / General Procedures - Air Conditioning (A/C) Clutch Air Gap Adjustment
Activation
-
NOTE:
Compressor with a spring rubber clutch shown others similar.
Check the A/C clutch air gap at 3 equally spaced places between the clutch plate and the A/C clutch pulley.
Refer to: Specifications (412-00 Climate Control System - General Information)
.
-
Remove the A/C clutch.
Refer to: Air Conditioning (A/C) Clutch and Air
Conditioning (A/C) Clutch Field Coil - 2.0L TDCi Bi-Turbo Diesel
(156kW/213PS) (YN)/2.0L TDCi Diesel (110kW/150PS) (BJ)/2.0L TDCi Diesel
(125kW/170PS) (P0) (412-00 Climate Control System - General Information)
.
Refer to: Air Conditioning (A/C) Clutch and Air
Conditioning (A/C) Clutch Field Coil - 3.0L Power Stroke Diesel (412-00
Climate Control System - General Information)
.
-
NOTE:
For some vehicles a shim kit may only be available with the A/C clutch assembly.
Add or remove spacers between the clutch plate hub and
the compressor shaft until the clearance is within specification.
Refer to: Specifications (412-00 Climate Control System - General Information)
.
-
For A/C clutch bolt or hub torque specification,
Refer to: Specifications (412-00 Climate Control System - General Information)
.
