Ford Escape 2020-2025 Service Manual / Powertrain / Engine / Accessory Drive - 1.5L EcoBoost (132kW/180PS) – I3 (Y1) / Removal and Installation - Accessory Drive Belt Idler Pulley
Ford Escape: Accessory Drive - 1.5L EcoBoost (132kW/180PS) – I3 (Y1) / Removal and Installation - Accessory Drive Belt Idler Pulley
Removal
-
Refer to: Accessory Drive Belt - Vehicles Built Up To: 1-October-2020
(303-05A Accessory Drive - 1.5L EcoBoost (132kW/180PS) – I3 (Y1),
Removal and Installation).
-
Loosen the bolt and remove the accessory drive belt idler pulley.
Torque: 18 lb.ft (25 Nm)
 |
Installation
-
To install, reverse the removal procedure.
-
Refer to: Accessory Drive Belt - Vehicles Built Up To: 1-October-2020
(303-05A Accessory Drive - 1.5L EcoBoost (132kW/180PS) – I3 (Y1),
Removal and Installation).
