Ford Escape: Climate Control System - General Information / Removal and Installation - Air Inlet Door Actuator
Removal
-
Remove the climate control housing.
Refer to: Climate Control Housing (412-00 Climate Control System - General Information, Removal and Installation).
-
Remove the screws and the air inlet door actuator.
-
Disconnect the electrical connector.
Installation
-
To install, reverse the removal procedure.
-
Using a diagnostic scan tool, carry out the Climate
Control System Actuator Calibration following the on-screen
instructions.
