Ford Escape: Climate Control System - General Information / Removal and Installation - Ambient Air Temperature Sensor

Removal

NOTE: Removal steps in this procedure may contain installation details.

With the vehicle in NEUTRAL, position it on a hoist.
Refer to: Jacking and Lifting - Overview (100-02 Jacking and Lifting, Description and Operation).

Disconnect the electrical connector. Detach and remove the ambient air temperature sensor.

Installation

To install, reverse the removal procedure.
- If replacing the ambient air temperature sensor a reset must be performed.
  Refer to: Reset the Outside Air Temperature Sensor Learned Values (412-00 Climate Control System - General Information, General Procedures).
