Ford Escape 2020-2024 Service Manual / Chassis / Brake System / Hydraulic Brake Actuation / Removal and Installation - Brake Master Cylinder - Vehicles With: Vacuum Brake Booster

Ford Escape: Hydraulic Brake Actuation / Removal and Installation - Brake Master Cylinder - Vehicles With: Vacuum Brake Booster

Removal

NOTICE: If the fluid is spilled on the paintwork, the affected area must be immediately washed down with cold water.

NOTE: Removal steps in this procedure may contain installation details.

  1. Remove the battery.
    Refer to: Battery (414-01 Battery, Mounting and Cables, Removal and Installation).
  1. Detach the brake booster tube from dash panel and position aside.
  1. NOTE: Make sure that all openings are sealed.

    If equipped.
    Disconnect the brake tube fittings.
    Torque: 159 lb.in (18 Nm)
  1. NOTE: Make sure that all openings are sealed.

    If equipped.
    Disconnect the brake tube fittings.
    Torque: 159 lb.in (18 Nm)
  1. Disconnect the brake fluid level sensor electrical connector.
  1. Remove the nuts and the brake master cylinder.
    Torque: 18 lb.ft (25 Nm)

Installation

  1. To install, reverse the removal procedure.
    • If a new brake master cylinder has been installed, bleed the master cylinder.
      Refer to: Component Bleeding - Vehicles With: Vacuum Brake Booster (206-00 Brake System - General Information, General Procedures).
    • If the brake master cylinder was removed to access other components, bleed the brake system.
      Refer to: Brake System Pressure Bleeding - Vehicles With: Vacuum Brake Booster (206-00 Brake System - General Information, General Procedures).
