Ford Escape: Parking Aid - Vehicles With: Active Park Assist / Removal and Installation - Front Active Park Assist Sensors

Removal

NOTE: LH side shown, RH side similar.

  1. Remove the front wheel and tire.
    Refer to: Wheel and Tire (204-04A Wheels and Tires, Removal and Installation).
  1. Remove the push pins and position aside the front wheel arch liner.

  1. Remove the front active parking aid sensor.
    1. Disconnect the front active park assist sensor electrical connector.
    1. Release the tabs.
    1. Remove the front active parking aid sensor.

Installation

NOTE: Make sure that the isolator rings are installed correctly while installing the sensors.

  1. To install, reverse the removal procedure.
  1. Carry out the azimuth system check.
    Refer to: Azimuth System Check (413-13C Parking Aid - Vehicles With: Active Park Assist, General Procedures).
  1. If any sensor fails the checks, diagnose the sensor fault.
    Refer to: Parking Aid (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Diagnosis and Testing).

    General Procedures - Azimuth System Check

    Check NOTE: Car shown, trucks are similar. Turn the ignition ON, engine OFF. Set the parking brake on. For automatic transmission place the selector lever in DRIVE (D)...

    Removal and Installation - Rear Active Park Assist Sensors

    Removal NOTE: RH side shown, LH side similar. Remove the rear wheel and tire. Refer to: Wheel and Tire (204-04A Wheels and Tires, Removal and Installation)...
