Ford Escape: Evaporative Emissions / Removal and Installation - Fuel Tank Isolation Valve - Plug-In Hybrid Electric Vehicle (PHEV)

Removal

  WARNING: Do not smoke, carry lighted tobacco or have an open flame of any type when working on or near any fuel-related component. Highly flammable mixtures may be present and may be ignited. Failure to follow these instructions may result in serious personal injury.

  WARNING: Do not carry personal electronic devices such as cell phones, pagers or audio equipment of any type when working on or near any fuel-related component. Highly flammable mixtures may be present and may be ignited. Failure to follow these instructions may result in serious personal injury.

  WARNING: Always disconnect the battery ground cable at the battery when working on an evaporative emission (EVAP) system or fuel-related component. Highly flammable mixtures may be present and may be ignited. Failure to follow these instructions may result in serious personal injury.

NOTE: Removal steps in this procedure may contain installation details.

  1. Remove the fuel vapor vent valve.
    Refer to: Fuel Vapor Vent Valve - Plug-In Hybrid Electric Vehicle (PHEV) (303-13C Evaporative Emissions, Removal and Installation).
    • Disconnect the electrical connector.
    • Disconnect the quick release couplings.
      Refer to: Quick Release Coupling (310-00 Fuel System - General Information - 2.5L Duratec – Hybrid (121kW/164PS) (BG)) .
    • Remove the isolation valve.

Installation

  1. To install, reverse the removal procedure.
