Ford Escape: Exterior Lighting / Removal and Installation - Light Sensor

Special Tool(s) / General Equipment

Interior Trim Remover

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Using a non-marring tool release and position the light sensor.
    Use the General Equipment: Interior Trim Remover
  1. Disconnect the electrical connector and remove the light sensor.

Installation

  1. To install, reverse the removal procedure.
