Ford Escape: Information and Entertainment System - General Information / Removal and Installation - Passenger Side Instrument Panel Speaker

Special Tool(s) / General Equipment

Interior Trim Remover

Removal

Position the speaker and grille up as an assembly.
Use the General Equipment: Interior Trim Remover

Disconnect and remove the speaker and grille as an assembly.

Release the tabs and remove the speaker.

Installation

To install, reverse the removal procedure.
