Ford Escape: Automatic Transmission - Automatic Transmission – HF45 / General Procedures - Transmission Fluid Drain and Refill
Materials
| Name |
Specification |
Motorcraft® MERCON® ULV Automatic Transmission Fluid XT-12-QULV |
WSS-M2C949-A, MERCON® ULV
|
Draining
-
With the vehicle in NEUTRAL, position it on a hoist.
Refer to: Jacking and Lifting - Overview (100-02 Jacking and Lifting, Description and Operation).
-
Remove the screws and the engine front undershield.
-
Remove the drain plug and drain the transmission fluid. Install the drain plug.
Torque:
106 lb.in (12 Nm)
Filling
NOTE:
The following procedure uses the Mityvac MVA7212 ATF Refill System.
-
Rotate the steering wheel counter clockwise to access the transmission fluid leveling plug.
-
Remove the transmission fluid leveling plug.
-
Install the adapter into transmission fluid leveling plug hole hand tight.
-
Fill the transmission with transmission fluid.
-
Fill the Mityvac MVA7212 with transmission fluid.
Material: Motorcraft® MERCON® ULV Automatic Transmission Fluid
/ XT-12-QULV
(WSS-M2C949-A, )
(MERCON® ULV)
-
Connect the Mityvac MVA7212.
-
Follow the manufacturer instructions to dispense the fluid into the transmission.
-
Release the pressure and remove the Mityvac MVA7212. Allow all excess fluid to drain into a pan.
-
Install the transmission fluid leveling plug.
-
Start the engine and allow to run for 1 minute. Turn engine off and wait 5 minutes.
-
Check the transmission fluid level.
-
The transmission fluid should be even with the bottom of the transmission fluid leveling plug hole.
-
Install the transmission fluid leveling plug.
Torque:
26 lb.ft (35 Nm)
-
Install the engine front undershield and the screws.
