Ford Escape: High Voltage Battery Charging System - Plug-In Hybrid Electric Vehicle (PHEV) / Removal and Installation - Charge Status Indicator (CSI) - Plug-In Hybrid Electric Vehicle (PHEV)

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Remove the LH fender splash shield. Refer to: Fender Splash Shield (501-02 Front End Body Panels).
  1. Disconnect the CSI electrical connector, detach the retainer and position the wire harness aside.
  1. Open the charge port door.
  1. Release the clips and remove the CSI housing from the vehicle.
    1. Remove the screws from the CSI .
    1. Release the retaining tab and remove the CSI .

Installation

  1. To install, reverse the removal procedure.
