Ford Escape: Bumpers / Removal and Installation - Front Bumper

Special Tool(s) / General Equipment

Interior Trim Remover

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Remove the front bumper cover.
    Refer to: Front Bumper Cover (501-19 Bumpers, Removal and Installation).
  1. Remove the push pins, release the tabs and remove the upper radiator air deflector.
    Use the General Equipment: Interior Trim Remover
  1. Remove the push pins, release the tabs and remove the lower radiator air deflector.
    Use the General Equipment: Interior Trim Remover
    1. Disconnect the horn electrical connector.
    1. On both sides.
      Remove the bolts and the horn and bracket assembly.
      Torque: 97 lb.in (11 Nm)
  1. Separate the wiring harness guides and position aside the wiring harness.
  1. Separate the wiring harness guides and position aside the wiring harness.
  1. Remove the cooling module.
    Refer to: Cooling Module (303-03A Engine Cooling - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Removal and Installation).
    Refer to: Cooling Module (303-03C Engine Cooling, Removal and Installation).
    Refer to: Cooling Module (303-03B Engine Cooling - 2.0L EcoBoost (177kW/240PS) – MI4, Removal and Installation).
  1. With the help of an assistant.
    Remove the bolts, the nuts and the front bumper.
    Torque: 46 lb.ft (63 Nm)

Installation

  1. To install, reverse the removal procedure.
