Ford Escape: Generator and Regulator / Removal and Installation - Generator - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Vehicles Built From: 2-October-2020
Removal
NOTE:
Removal steps in this procedure may contain installation details.
-
Disconnect the battery.
Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
-
Remove the air conditioning (A/C) compressor inlet line.
Refer to: Air Conditioning (A/C) Compressor Inlet Line - 1.5L EcoBoost
(132kW/180PS) – I3 (Y1) (412-00 Climate Control System - General
Information, Removal and Installation).
-
Detach the retainers and position the degas hose aside.
-
Detach the retainers and position the wire harness aside.
-
-
Remove the accessory drive belt shield nut.
Torque:
119 lb.in (13.5 Nm)
-
Remove the studbolt and the accessory drive belt shield.
Torque:
119 lb.in (13.5 Nm)
-
Remove the accessory drive belt.
Refer to: Accessory Drive Belt - Vehicles Built From: 1-October-2020
(303-05A Accessory Drive - 1.5L EcoBoost (132kW/180PS) – I3 (Y1),
Removal and Installation).
-
NOTICE:
When installing the B+ terminal nut to the
generator, finger-start the nut before tightening or component damage
may occur.
Disconnect the generator electrical connector. Remove the B+ terminal cover and nut. Position the B+ wire aside.
Torque:
155 lb.in (17.5 Nm)
-
-
Remove the generator bolt.
Torque:
18 lb.ft (25 Nm)
-
Remove the studbolt and the generator.
Torque:
18 lb.ft (25 Nm)
Installation
-
To install, reverse the removal procedure.
-
Do not fully tighten the generator bolts until all of the bolts are installed finger-tight.
General Specifications
Item
Specification
1.5L EcoBoost Vehicles
Rating
180 amps
Generator amps at 80...
