Ford Escape 2020-2024 Service Manual / Powertrain / Engine / Starting System - 1.5L EcoBoost (132kW/180PS) – I3 (Y1) / General Procedures - Starter Motor Drive Gear and Flywheel Ring Gear Inspection

Ford Escape: Starting System - 1.5L EcoBoost (132kW/180PS) – I3 (Y1) / General Procedures - Starter Motor Drive Gear and Flywheel Ring Gear Inspection

Activation

  1. Refer to: Starter Motor (303-06C) .
  1. Check the wear patterns on the starter drive gear and the flywheel or flexplate ring gear. If the wear pattern is normal, install the starter motor.
    Refer to: Starter Motor (303-06C) .
  1. If the starter drive gear and the flywheel or flexplate ring gear are not fully meshing and the gears are scored or damaged, install a new starter motor.
    Refer to: Starter Motor (303-06C) .
  1. If necessary, install a new flywheel or flexplate.
    Refer to: Flexplate (303-01C) .

    General Procedures - Starter Amperage Draw Test

    NOTE: Make sure the test is performed with the engine at 60.8 °F ( 16 °C) or above. Make sure the battery is fully charged. For additional information, refer to: Specifications (414-01 Battery, Mounting and Cables - 6...

    Removal and Installation - Starter Motor

    Removal NOTE: Removal steps in this procedure may contain installation details. Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation)...
