Ford Escape: Front Disc Brake / Removal and Installation - Brake Disc Shield

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Remove the brake disc.
    Refer to: Brake Disc (206-03 Front Disc Brake, Removal and Installation).
  1. Remove the bolts and brake disc.
    Torque: 80 lb.in (9 Nm)

Installation

  1. To install, reverse the removal procedure.
